82

AFTER OPERATION WITH WATER FILTER

60B

After operation with

„water filter unit”

 it is necessary to perform proper activities in order to clean

inner elements of the tank and prepare it for storage.

−

  Switch the vacuum cleaner off and unplug it.

−

  Remove the hose ending.

−

 Black surface

−

 remove the water filter unit from the vacuum cleaner.

−

  Remove the inner module from the tank.

−

  Press the flexible hook of the separator frame with your finger, disassemble the water separator and

remove initial filter.

−

  If it is necessary, remove the node, flush it and assemble again, taking care for proper assembling.

−

 Water filter unit - clean tank, separator and initial filter under running water. Clean the parts

thoroughly.

−

   Dry after cleaning. You can do it in two different ways:

1. Disassemble the parts and leave them until they get dry. Assemble

after drying and insert complete tank into the vacuum cleaner.

2. Assemble complete vacuum cleaner after cleaning (without water) and

switch it on for about 5 min. (Drying with airflow).

ATTENTION!!! Leaving not completely dried parts inside the assembled

vacuum cleaner can cause unpleasant smell.

In case of incidental getting the accessories wet (tubes, hose or nozzles inside)
you should stop the vacuuming switch the vacuum cleaner off and dry the wet
parts.
In order to do it, please set the air recirculation module knob in blowing position and switch the
vacuum cleaner on for about 2 min. The activity is performed to dry the hose, pipes and other
accessories in contact with water. It prevents bacteria development during storage

.

FILTERS CONTROL

 The vacuum cleaner is equipped with the following filters:

1. Separator and initial filter

Activities connected with cleaning are described in part concerning after
operation activities.

−

  Washing of these parts shall be held after each vacuuming.

−

  Assemble the parts In reverse sequence to disassembling

−

   Be careful during assembling initial filter, so that black surface of the filter

was outside (up).

2. Final filter (HEPA filter for type 819.*.***S)
Final filter removing

−

  Remove the back tank from the housing and turn the vacuum cleaner

so that it was supported with upper, inclined surface and the handle
on the floor.

−

  Move the cursor into such position, that

the open mark was visible

.

−

  Open the filter lid according to the figure

beside.

−

  Catch the fin to remove the final filter.

Black

surface

Open

Black

surface
