79

APPLICATION
OF ACCESSORIES

The sucking hose

is a basic element of the vacuum cleaner equipment. Its

flexibility enables easy manipulation with other accessories.
The endings of the hose are connected so that they prevent twisting the
hose during operation. There is an inlet with suction power adjustment at one
of the endings.

Telescope suction tube

connects the nozzles and brushes with sucking

hose extending the distance of cleaning area. The tube construction makes
possible to adjust its length during cleaning depending on the size of the
User.
You can achieve desired length moving

„A”

button in direction indicated by

the arrow. Maximum tube length = 96 cm.

Accessories,

such as nozzles: small land gap and small brush are placed in

the accessories compartment under the front lid of the vacuum cleaner.

Small nozzle

is intended for vacuuming soft surfaces such as:

curtains, draperies, upholstered furniture etc.

Small brush

is intended for vacuuming rough

surfaces such as: libraries, picture frames etc.

Gap nozzle

is intended for picking up dirtiness from places of difficult access like the

gaps in panelling, skirting, heaters, etc.

Nozzle- brush

is universal element of equipment. It can be used both  as a brush

and as a nozzle. You can change it switching appropriate button. Pressing button
backwards

 (marked at the housing) makes the brush appear from the casing, it

can be used for vacuuming hard surface, i.e. wooden floors, laminates, tiles or walls.

Pressing button forwards

 (marked at the housing) The nozzle brush is prepared

for operation as a nozzle and it is intended for soft surface cleaning, i.e. carpets, fitted carpets.

„BNB” – „B

rush

 N

atural

 B

ristle

”

It is used for cleaning and polishing hard surfaces, sensitive for scratching, i.e.
wooden floor, laminate, parquet, marble, tiles, walls, coverings made of noble
materials, etc.

Gentle and soft natural bristle provides maximum vacuuming efficiency and protects

against scratching cleaned surface.

Small nozzle

Gap nozzle

Small brush

Telescope extension tube

W

ąż

 ss

ą

cy

SAFBAG (bag)

Separator

49 .4 00 0

Water

measuring vessel

Nozzle-brush

Initial filter

Black

surface

Foam neutralizing

agent

Accessories

cover

Cable rewind

button

Water filter unit

Air recilculation

module knob

Back water

tank

Pipe node

Initial filter

On/off

button

SAFBAG (bag)

unit
