24

Replacement of rear filter for motor

The rear filter for motor is installed behind the air outlet grid, which can be was-
hed due to the materials used . When the surface is jammed seriously by dust, the
filter should be replaced by a new one or washed by water to maintain enough
suction force

10

 and

11

 .

It is usually necessary to clean and replace the filters for motor only after they
have been used for 6 months to 12 months . Please remember to confirm that
all filters have been correctly installed into the machine before turning on the
vacuum cleaner to use .

Key Points:

The power supply of the vacuum cleaner must be cut off before

replacing any filter!

Faults and repair

In case of abnormality with this product, please treat it in the way as stated
hereinafter; if the vacuum cleaner still refuses to work normally, please contact
the stop from where this product was bought or with the appointed service point .

Fault

Treatment

The vacuum cleaner
cannot operate .

1 . Check whether the power plug is inserted securely; pull out the plug and then reinsert it in the power socket;
2 . Check whether the power socket is electrified;
3. Check whether the switch of the vacuum cleaner is in „ON“ position

.

The suction force is
reduced

1 . Check whether the floor brush, the hose and the spile are jammed, and remove any blockage immediately;
2. Check whether the air-inlet filter gauze is dusty; frequently clean rubbish or replace air-inlet and air-outlet;

There is abnormal
sound when the motor
is under operation .

Stop the vacuum cleaner immediately;
Check whether the floor brush, the hose and the spile are jammed, and remove any blockage immediately .

Cleaning of front filter for motor

Warning: please make sure the power supply of the vacuum cleaner has been cut
off before carrying out the following steps:
1 .  Pull out the power cord plug of the vacuum cleaner from the power socket .
2 . Press down the handle of the cyclone dust barrel to remove the cyclone dust
  barrel, and remove the cover of the front filter for motor, and then use the
  brush to clean the filter (sponge and filter gauze with composite coating) or
  place it under the cock to clean, as is shown in

8

 and

9

 .

Caution:

It is normal that the white central filter in the cyclone dust barrel may

change color, which cannot affect its filtration performance . If the hose and the
central filter are difficult to clean, we recommend that you use water to flush
them; however, please be sure to place them in the dry air for at least 24 hours
after they are flushed by water .

Please note:

when the cyclone dust collecting barrel or the filter cover is
not installed in place, the operation status will be invalid, and
the vacuum cleaner will have no dust absorption capacity . At
this time, you need to check carefully whether the cyclone dust
collecting barrel and the filter cover have been installed in place .

8

9

10

11

1.

2.
