23

Operation Instructions

How to start

1 . First of all, pull out the power cord from the cord reel to the needed length;
  insert the power cord plug into the power socket, and press down the power
  switch button with finger or step on it with foot; then you can control the start
  and stop of the vacuum cleaner .
2. The yellow mark on the power cord indicates its desired length. Never pull out
  the power cord to the length exceeding the red mark.

Protective devices of motor

1 . There is a temperature controller designed in the body of vacuum cleaner
  motor, which can automatically cut off the power supply of motor to prevent
  overheating. When the air-inlet or air-outlet pipe is overloaded or blocked,
  the temperature of motor rises, then the temperature controller cuts off the
  power supply of motor automatically to make the motor cool, preventing the
  cleaner from being damaged .
2 .  If the temperature controller is cut off, stop the vacuum cleaner immediately
   and pull out the power plug to make the cleaner cool, and check and remove
  the hair roll or other roll-like rubbish blocking the air inlet (including the hose
  and the spile), and replace the filter or filter gauze when necessary .
3. After cooling the motor for 30mins, plug in the power plug and check whether
  the temperature controller has been reset . If the power supply of the vacuum
  cleaner hasn‘t been cut off, the temperature controller of the motor won‘t be
  reset even when the motor has become cool .

Maintenance of the Vacuum Cleaner

1.  All the day-to-day maintenance and repair jobs should be done after the
  power plug has been pulled out .
2 .  Frequently remove the rubbish from the cyclone dust barrel, so as to avoid the
  failure of the vacuum cleaner .
3.  Never wipe the surface of the vacuum cleaner with gasoline or oily liquid.
  Wipe it with water or neutral detergent .


Caution:

be sure to wring out the wiping cloth dry for wiping, it is prohibited

  for water to infiltrate into electrical elements of the vacuum cleaner .
4 .  When the vacuum cleaner is placed idle not in use, it should not be put directly
  in the sun or in a damp place

 .

Storage of the Vacuum Cleaner

1.  Upon the completion of the operation of the vacuum cleaner, turn off its power
  supply, and pull the power plug out of the power socket, then step on the cord
  reeling button to reel in the power cord fully . Hang the floor brush onto the

  floor brush hook, as is shown in

6

  .

2 .  Place the vacuum cleaner in the dry indoor environment .

GB

Cleaning of the Cyclone Dust Barrel

Remove the rubbish in the cyclone dust barrel frequently to avoid the failure of
the cleaner .
1 .  Clean the cyclone dust barrel only after the power plug of the cleaner has been
  pulled out .
2.  Put the cyclone dust barrel over the rubbish bin (bag), press down the
  releasing button of the cyclone dust barrel, the bottom cover of the cyclone
  dust barrel will automatically fall down, and clear and empty the cyclone dust

  barrel, as is shown in

7

 .

1.

2.

5

6

7
