Assembly of the Filter Unit

1.

Place the coarse filter in the dust container. Please note

the recess on the edge of the dust container. Now push

the coarse filter down so that it is placed in the center of

the dust container.

2.

Put the fine material filter (with the coloured fabric part

facing up) onto the coarse filter. Firmly press on the fine

material filter.

3.

Then reattach the dust container to the handset. First,

place the dust container on top of the motor housing.

Now push the dust container down. The latch on the dust

container must audibly snap into place.

Outlet Filter

The appliance is also equipped with an exhaust filter. It is

located at the top of the motor housing.

  CAUTION:

You

cannot

 remove this filter.

Cleaning

  WARNING:

•  Always disconnect the appliance from the power adapter before

cleaning!

•  Under no circumstances should you immerse the motor housing

in water in order to clean it. Otherwise this might result in an

electric shock or fire.

  CAUTION:

•  Do not use a wire brush or any abrasive items.

•  Do not use any acidic or abrasive detergents.

•

The single components are not dishwasher-safe.

•  Wipe the casing with a damp cloth.

•

You can wipe the power adapter unit with a dry cloth.

Floor Nozzle

1.

Disconnect the floor nozzle from the suction pipe.

2.

Turn the floor nozzle

around, so that you

see the lower side.

Use a small coin or

any other tool to open

the latch. Direction of

rotation: Counterclock-

wise. Flip the cover

open.

3.  Pull out the brush roller.

4.

Remove threads and hair wound to the brush. Use

scissors, if required.

5.

Assembly:

5.1  Put the brush roller, with the star-shaped recess

first, back into the compartment.

5.2  Insert the other end of the brush roller with the

square bearing into the recess underneath the

cover.

6.  Close the lock of the brush roller.

Dust Container with Filter Unit

Please read the chapter “Maintenance” for cleaning of these

components.

Storage

•  Clean the appliance as described and allow it to dry.

•  For storage, use the previously mounted wall bracket or

carefully place the appliance on the floor.

•  We recommend that you keep the appliance in the origi-

nal packaging if it will not be used for long periods.
