ENGLISH

en

13

instruction on how to use this

vacuum cleaner.
Warning sign for machines with

dust class L:

While the appliance is suitable for

extracting substances that pose a

slight threat to health, it is not

appropriate for reducing wood dust

in inhaled air.
Dust from material such as paint

containing lead, some wood

species, minerals and metal may

be harmful. Contact with or

inhalation of the dust may cause

allergic reactions and/or

respiratory diseases to the

operator or bystanders.

Certain kinds of dust are classified

as carcinogenic, such as oak and

beech dust, especially in

conjunction with additives for wood

conditioning (chromate, wood

preservative).

See page 3.

1 Upper part

2 Mains connection lead

3 Snap  locks

4 Container

5 Switch for switching On/Off

6 Switch for automatic On/Off *

7 Plug socket for power tool *

8 Guide  roller

9 Wheel

10 Pipe support *

11 Pleated filter

12 Bayonet fitting on pleated filter

13 Paper filter bag *

14 Motor protection filter

15 Water sensor (float valve)

* depending on equipment/not included in scope of

delivery

Before plugging in the device, check that

the rated mains voltage and mains

frequency, as specified on the rating label,

match your power supply.

Australia: Always use a residual current

device (RCD) protected supply with a

rated residual current of 30 mA or less.

6.1 Assembly

Insert the guide roller axles (8) until they engage

Fig. A.

Fit the wheels (9) and secure with

screws (place a shim under the screw head)

Fig. B

.

Fit the pipe support (10) until it clicks into place, as

shown (for ASA 32 L only)

Fig. C

.

6.2 Fitting the pleated filter

Fig. D+E:

Fit the pleated filter (11) on the

housing as far as the limit stop and secure by

twisting the bayonet fitting (12).

6.3 Inserting the paper filter bag

Paper filter bags (13) are not suitable for wet vacu-

uming.
We recommend using paper filter bags for:
- Applications, where small amounts of fine dust are

created (e.g. spot-grinding and grinding of paint

and lacquer coatings, extraction of drilling

applications with small diameters < 10 mm of

short duration, etc.).

- Use of machines, such as: routers, planers, small

grinding machines, etc.

When using a fleece/paper filter bag the filter

cleaning is non-functional.
Switch off the appliance, remove the mains plug

and open the snap locks (3). Remove the upper part

(1) from the container (4).
Push the paper filter bag together with its cardboard

tab into the filter bag holder located on the suction

piece (inside the container)

Fig. F

.

Adjust the paper filter bag (13) so that it is flush with

the container wall and is not damaged when you

replace the upper part.
Remove the paper filter bag if you want to vacuum

coarser materials or liquids.

7.1 Switching On/Off, automatic operation

Use the switch (5) to turn the machine On/Off.

Switch position I :  "ON"

Switch position 0:  "OFF"

For ASA 32 L only:

Use the  (6) switch to activate automatic

On/Off

.

If the  (6) switch is in the "A" position and the  (5)

switch is in the "I" position, the vacuum cleaner can

be activated or deactivated by a power tool

connected to the power socket (7).

5. Overview

6. Initial Operation

7. The Appliance
