3

Packing List

Main-body Assembly

Assemble the electric floorhead and

metal tube .

Hold the floor head with left hand, use right hand
to insert the metal tube vertically into floor head,
align with the conductive needle, press the
handle until a “click” sound is heard.

Attention:Keep the handle and floor head in the same

direction, conductive needle shall align with the socket.

When packing, storing or cleaning, if the electric
floorhead needs to be removed, press the brush
release button as shown in the picture and pull
the electric floorhead in the direction shown in
the picture.

Assemble battery pack and handheld

vacuum Cleaner

Assembly of battery pack: hold the hand-held
vacuum cleaner in one hand, hold the battery
pack in the other hand, aim at the guiding
groove on the body, slide in the battery pack
according to the arrow direction shown in the
picture, and then pull the battery pack after
installation to make sure it does not get loose.

Attention: when the vacuum cleaner is long idled, please

remove the battery, pack the machine and store it in

a cool and dry place, avoid direct sunlight or humid

environment.

Part Name

Handheld

Vacuum Cleaner

ElectricFloor

head

Electric mattress

head

2-in-1 upholstery

tool

2-in-1 crevice tool

Quantity

1

1

1

1

1

Part Name

Soft brush

Charging holder

Connector

Stretch hose

Flexible metal tube

Quantity

1

1

1

1

1

Part Name Carpet  brushroll

Adaptor

Screw

expansion pipe Instruction manual

Quantity

1

1

2

2

1

1

2
