JIMMY JV85 Pro - Инструкция по эксплуатации - Страница 4

2

Products Installation

Unpacking

 Open the package, take out the foam pad , all accessories and machine from the package, take
off the plastic bag and save them for the purpose of future maintenance and repair.

Parts Name

1.Switch button
4 .Flexible metal tube
7.LED screen
10.Charging holder
13.Electric mattress head
16.Stretch hose

2.Power button
5. Floor head release button
8.Dust cup release latch
11.2-in-1 crevice tool
14. Connector
17.Carpet brushroll

3.Metal tube release button
6.Battery pack release button
9.Charger
12.2-in-1 upholstery tool
15.Soft brush

12

9

11

13

14

16

17

15

3

2

1

5

4

6

7
8

10
