EN

USING YOUR DYSON APPLIANCE

PLEASE READ THE ‘IMPORTANT SAFET Y INSTRUCTIONS’ IN THIS DYSON
OPER ATING M ANUAL BEFORE PROCEEDING.

OPER ATION

•

Do not use outdoors or on wet surfaces or to vacuum water or other liquids –

electric shock could occur.

•

Ensure the appliance remains upright in use and in storage. Dirt and debris may

be released if it is turned upside down.

•

Do not operate while checking for blockages.

•

For domestic indoor and car use only. Do not use it whilst the car is in motion or

while driving.

•

To operate the Max mode, hold the trigger down and press the ‘Max’ button.

The ‘Max’ button will light up.

•

To switch off Max mode, hold the trigger down and press the ‘Max’ button

again. Note: The appliance will retain the last used mode. So if you use it in max

mode and do not disengage it, the appliance will operate in Max mode when it

is next used until you depress the ‘Max’ button to disengage it.

•

This appliance has carbon fibre brushes. Take care if coming into contact with

them, as they may cause minor skin irritation. Wash your hands after handling

the brushes.

DOCKING STATION INSTALLATION

•

Use appropriate mounting hardware for your wall type and ensure that the

docking station is mounted securely. Ensure no pipe work (gas, water, air) or

electrical cables, wires or ductwork are located directly behind the mounting

area. The docking station must be mounted in accordance with regulations

and applicable codes/standards (state and local laws may apply). Dyson

recommends the use of protective clothing, eyeware and materials when

installing the docking station.

CARPETS OR HARD FLOORS

•

Before vacuuming your flooring, rugs and carpets, check the manufacturer’s

recommended cleaning instructions.

•

The brush bar on the appliance can damage certain carpet types and floors.

Some carpets will fuzz if a rotating brush bar is used when vacuuming. If this

happens, we recommend vacuuming without the motorised floor tool and

consulting with your flooring manufacturer.

•

Before vacuuming highly polished floors, such as wood or lino, first check that

the underside of the floor tool and its brushes are free from foreign objects that

could cause marking.

LOOKING AFTER YOUR DYSON APPLIANCE

•

Do not carry out any maintenance or repair work other than that shown in this

Dyson Operating Manual, or advised by the Dyson Helpline.

•

Only use parts recommended by Dyson. If you do not this could invalidate

your guarantee.

•

Store the appliance indoors. Do not use or store it below 3°C (37.4°F). Ensure

the appliance is at room temperature before operating.

•

Clean the appliance only with a dry cloth. Do not use any lubricants, cleaning

agents, polishes or air fresheners on any part of the appliance.

VACUUMING

•

Do not use without the clear bin and filter in place.

•

Fine dirt such as flour should only be vacuumed in very small amounts.

•

Do not use the appliance to pick up sharp hard objects, small toys, pins, paper

clips, etc. They may damage the appliance.

•

When vacuuming, certain carpets may generate small static charges in the

clear bin or wand. These are harmless and are not associated with the mains

electricity supply. To minimise any effect from this, do not put your hand or

insert any object into the clear bin unless you have first emptied it. Clean the

clear bin with a damp cloth only. (See ‘Cleaning the clear bin’.)

•

Use extra care when cleaning on stairs.

•

Do not rest the appliance on chairs, tables, etc.

•

Do not press down on the nozzle with excessive force when using the appliance

as this may cause damage.

•

Do not leave the cleaner head in one place on delicate floors.

•

On waxed floors the movement of the cleaner head may create an uneven

lustre. If this happens, wipe with a damp cloth, polish the area with wax, and

wait for it to dry.

DIAGNOSTICS – MAIN BODY

When in use, trigger pressed:

EMPTYING THE CLEAR BIN

•

Empty as soon as the dirt reaches the level of the M A X mark – do not overfill.

•

Ensure the appliance is disconnected from the charger before emptying the

clear bin. Be careful not to pull the 'ON' trigger.

•

To make emptying the clear bin easier, it is advisable to remove the wand and

floor tool.

•

To release the dirt, push the red button by the clear bin: Press once to open the

bin base. Press a second time to release the clear bin from the main body of

the appliance.

•

To minimise dust/allergen contact when emptying, encase the clear bin tightly in

a plastic bag and empty.

•

Remove the clear bin carefully from the bag.

•

Seal the bag tightly, dispose as normal.

•

Close the clear bin base so it clicks into place and is secure.

CLEANING THE CLEAR BIN

•

Ensure the appliance is disconnected from the charger before removing the

clear bin. Be careful not to pull the ‘ON’ trigger.

•

Remove the wand and floor tool.

•

Push the red button by the clear bin: Press once to open the bin base. Press a

second time to release the clear bin from the main body of the appliance.

•

Remove the clear bin carefully.

•

Clean the clear bin with a damp cloth only.

•

Do not use detergents, polishes or air fresheners to clean the clear bin.

•

Do not put the clear bin in a dishwasher.

•

Clean the cyclone shroud with the brush on the combination tool to remove lint

and dust.

•

Ensure the clear bin is completely dry before replacing.

•

To replace the clear bin, push the clear bin up and in to the main body of the

appliance. It will click into place.

•

Close the clear bin base so it clicks into place and is secure.

WASHING YOUR FILTER

•

Ensure the appliance is disconnected from the charger before removing the

filter. Be careful not to pull the ‘ON’ trigger.

•

Your appliance has one washable filter, located as shown.

•

To remove the filter, lift it out of the top of the appliance.

•

Check and wash the filter regularly according to instructions to

maintain performance.

•

The filter may require more frequent washing if vacuuming fine dust or if used

mainly in ‘Powerful suction’ mode.

•

Wash the filter with cold water only. No hot water and no detergents.

•

Run water over the outside of the filter until the water runs clear.

•

Squeeze and twist with both hands to make sure the excess water is removed.

•

Lay the filter on its side to dry. Leave to dry completely for a minimum of

24 hours.

•

Do not put the filter in a dishwasher, washing machine, tumble dryer, oven,

microwave or near a naked flame.

•

To refit, place the dry filter back into the top of the appliance. Make sure it is

seated properly.

LOOKING FOR BLOCK AGES

•

Ensure the appliance is disconnected from the charger before looking for

blockages. Be careful not to pull the ‘ON’ trigger.

•

Do not operate while checking for blockages. Doing so could result in

personal injury.

•

Beware of sharp objects when checking for blockages.

•

To gain access to blockages in the floor tool, remove the base plate by using a

coin to loosen the screw marked with a padlock.

•

If you cannot clear an obstruction you may need to remove the brush bar. Use

a coin to unlock the fastener marked with a padlock. Remove the obstruction.

Replace the brush bar and secure it by tightening the fastener. Ensure it is fixed

firmly before operating the appliance.

•

This product has carbon fibre brushes. Take care if coming into contact with

them, as they may cause minor skin irritation. Wash your hands after handling

the brushes.

•

Refit all parts securely before using.

•

Clearing blockages is not covered by your guarantee.

BLOCK AGES – THERMAL CUT-OUT

•

This appliance is fitted with an automatically resetting thermal cut-out.

•

Large items may block the tools or nozzle. If any part becomes blocked the

appliance may overheat and automatically cut-out.

•

Leave to cool down for 1-2 hours before checking the filter or for blockages.

•

Ensure the appliance is disconnected from the charger before looking for

blockages. Failure to do so could result in personal injury.

•

Clear any blockage before restarting.

•

Refit all parts securely before using.

•

Clearing blockages is not covered by your guarantee.

CHARGING AND STORING

•

This appliance will switch ‘OFF’ if the battery temperature is below 3°C

(37.4°F). This is designed to protect the motor and battery. Do not charge the

appliance and then move it to an area with a temperature below 3°C (37.4°F)

for storage purposes.

•

To help prolong battery life, avoid recharging immediately after a full discharge.

Allow to cool for a few minutes.

•

Avoid using the appliance with the battery flush to a surface. This will help it run

cooler and prolong battery run time and life.

DIAGNOSTICS – BATTERY

When in use, trigger pressed:

Solid blue: Max 'ON'.

Light off: Powerful suction.

Flashing blue: Low battery warning.

Fast flashing blue: No power, temporary fault

(e.g. check filter or for blockages).

Solid blue: 'ON'.

Flashing blue: No power, charge battery.

Flashing amber: No power, temporary fault

(e.g. too hot/cold).

Flashing red: Fault (contact Dyson Helpline).

Solid amber: Fault (contact Dyson helpline).

32
