17

PICKING UP WATER

If you want to use the vacuum cleaner to vacuum liquid in

the container, the vacuum cleaner should be prepared as in

the case of vacuum cleaning with the use of the water filter

module except that:

1.  The container should be empty (without water).

2. You are to use atomizing nozzles (large or small), large

atomizing nozzle with the gathering attachment or the

nozzle for picking up water.

  Do not operate the vacuum cleaner with a full

container! Do not vacuum large amounts of

liquid  at  a  time  (e.g.  with  the  hose  immersed

into water).

If the water exceeds the maximum level during vacuuming,

the  float  will  automatically  block  the  suction.  The  maximum

capacity of the container is about 5 l. In such a case proceed

in the manner described above in the part concerning the

blocking  of  suction  caused  by  a  dirty  foam  filter  (pulsating

motor speed).

END OF OPERATION CLEANING AND MAINTENANCE

●

Switch off the vacuum cleaner by pressing the on/off

button

(8)

 and unplug the appliance.

●

Wind the cord by pressing the cord rewind button

(9)

.

While doing this hold the cord to make sure it is not tangled

and the plug does not hit the vacuum cleaner housing.

●

Turn the end of the hose until the tops of the marks

on the end of the hose end and on the vacuum cleaner

housing are in the same position and pull the hose out

of the opening.

●

Remove the stub pipe of the hose by pressing the red

button on the valve and pull the stub pipe.

●

Disconnect the telescopic tube from the hose and the

nozzle or brush.

●

Pour the dirty water out of the container.

●

It  is  recommended  to  wash  the  container,  filters

(disassembly below) and partition thoroughly after each

use – changing water several times.

●

After using the wet cleaning function thoroughly wash

all attachments used in this process (hose, tubes,

accessories).

  If you do not clean the above-mentioned parts

or  clean  them  insufficiently  it  may  lead  to  the

loss  of  the  filtration  capabilities  of  the  inserts

and foam and cause the formation of bacteria

and mites.

Dry  all  the  cleaned  parts  thoroughly  before

reassembly.

FILTER DISASSEMBLY
FOAM FILTER I

1

 Open  the  lid  of  the  filtration  unit  by  pulling  the  handle

upwards.

2

 Take  out the filter, wash  it under  running  water, dry and

reinsert.

G

●

Close  the  filtration  unit  lid  by  pressing  it  until  you  hear

a characteristic click.

FOAM FILTER II

It is recommended to wear rubber protective gloves while

dismantling the filter.

1

 Grab the foam filter with your fingers and remove it from

the filtration unit body.

2

 Wash under running water, dry and reinsert.

  Do not hand wash the filter foam, do not wring

it,  do  not  wash  it  in  washing  machines. Avoid

crumpling,  stretching  and  deforming.  After

cleaning  dry  the  foam  in  room  temperature.

Never dry the foam on heaters, stoves, etc.

EPA/HEPA OUTLET FILTER

AND COOLING AIR FILTER

The EPA/HEPA outlet filter should be replaced after about 30

hours of operation (6 months) or earlier in case of heavy dirt.

1

 Slide  the  slider  of  the  filter  cover  interlock  downwards

and open the filter cover.

2

 Remove and replace the EPA/HEPA filter with a new one

when the filter becomes dirty.

3

 Remove  and  replace  the  motor  filter  with  a  new  one

when the filter becomes dirty.

4

 It is possible to rinse the EPA/HEPA filter and the cooling

air  filter  under  running  water.  Remember  to  dry  the  above

mentioned filters before reassembly.

●

Close  the  filter  cover  and  slide  the  interlock  slider

upwards.

TURBO BRUSH

Turbobrush description

Turbobrush is a suction nozzle with rotating, turbine driven

brush. It is intended only for vacuum cleaners to clean

carpets  and  fitted  carpets.  Plastic  casing  ensures  esthetic

appearance.  Rotating  brush  enables  removing  difficult

rubbish, such as threads, rags, paper, etc. It is especially

useful in houses with animals (cats, dogs), where removing

fur from carpets is very burdensome. Brush roller is driven

by turbine placed in the joint, by means of belt transmission.

Proper position of the regulator ensures correct work of the

turbobrush, depending on height of carpet hair and facilitates

its movement along the carpet.
