 Small nozzle

19

 Crevice nozzle

20

 Telescopic suction tube

21

 Suction hose

22

 Dust bag holder

23

 Water filter module:

A

 Filtration unit

B

 Partition

24

 Container

25

 Cleaning liquid container

26

 Spray unit – suction hose handle attachment

27

 Large atomizing nozzle

28

 Small atomizing nozzle

29

 Water pick up nozzle (BWD41720, BWD420HYG,

BWD421PET, BWD421PRO)

30

 Rubber slat to the large atomizing nozzle

31

 Washing set

32

 Foam filter I (installed in the vacuum cleaner)

33

 Foam filter II (installed in the vacuum cleaner)

34

 Motor filter (installed in the vacuum cleaner)

35

 EPA/HEPA outlet filter (installed in the vacuum cleaner)

Preparing the vacuum cleaner for

operation

1

 Insert the end of the suction hose to the vacuum cleaner

opening so that the markings   on the hose end and on the

vacuum cleaner housing are opposite each other and turn
the hose clockwise to the position  .

2

 Connect the other end of the hose (handle) with the

telescopic suction tube.

3

 Hold the ring on the pipe and set chosen length putting it

in or out.

4

 Assemble the appropriate nozzle or brush to the other

end of the suction tube.

5

 Use the following nozzles and brushes for traditional using

the water filter module: combination carpet & floor brush with

small objects separator, small nozzle, small brush, crevice

nozzle, mattress nozzle, parquet brush or turbo brush.

6

 You may assemble a basket for picking up small objects

in the combination brush with small item separator. In order

to do so remove the basket cover and insert the basket.

7

 To  clean  hard  surfaces  –  wooden  floors,  plastic  floors,

ceramic tiles etc. pull out the brush by pressing the switch on

the nozzle according to the figure

.

8

 The vacuum cleaner is equipped with an accessory

compartment. The compartment opens/closes with the use

of a slider. To open/close the compartment side the slider

downwards/upwards and take out/ put away the desired nozzle.

9

 The vacuum cleaner may be stored in a horizontal

B

position; in order to this, place the fastening hook of the

combination nozzle/brush into its fastening. The hose may

be left attached to the vacuum cleaner, but it is important to

pay attention not to leave it heavily bent during storage.

10

 Close the lid.

11

 Grab the plug

(4)

 and pull the cord out of the vacuum

cleaner.

●

Plug in the appliance.

 Before switching on the vacuum cleaner

with  the  on/off  button  (8),  make  sure  that  the

appropriate module is installed in the container

(see section C, E, or F).

12

 Switch on the vacuum cleaner by pressing the “on/off”

button

(8)

.

In order to prepare the vacuum cleaner for wet operation

additionally:

13

 Assemble the spray unit – the suction hose handle

attachment

(26)

.

●

Attach the hose fastenings to the suction hose and the

telescopic suction tube.

14

 Attach the end of the hose (sleeve) to the telescopic

suction tube and insert the other end of the hose in the small

atomizing nozzle or the large atomizing nozzle until you hear

a characteristic click.

15

 Use the following nozzles for the wet vacuuming and wet

cleaning function or to pick up water: large atomizing nozzle,

small atomizing nozzle or the water pick up nozzle.

16

 Slide the stub pipe valve plug downwards.

●

Insert the stub pipe of the hose to the valve in the

vacuum cleaner housing.

●

Make sure the stub pipe fastenings snap shut.

  In  case  of  difficulties  in  connecting  the  above

mentioned  elements  moisten  the  gaskets  e.g.

with technical vaseline, water, etc.

Vacuum cleaner functions

TRADITIONAL CLEANING WITH DUST BAG

1

 Press and hold the container lid opening button

(2)

 and

lift the container lid.

2

 Put the holder

(22)

 into the container. Make sure the

holder is inserted correctly in the container guide slots and

the safety lock is engaged. Unfold the bag in the container.

  Do  not  put  holder  into  a  wet  container.

Thoroughly dry a wet container. Dust bag must

not get wet.

3

 Cover the container with the filtration unit.

  If the holder is not attached properly, the safety

lock  will  prevent  covering  the  container  with

the filtration unit.

C
