37

Vacuuming

Figure

Adjusting the floor tool:

Rugs and carpets

=>

Hard surfaces

=>

Caution!

Floor tools are subject to a certain amount of wear,
depending on the type of hard floors you have
(e.g. rough, rustic tiles). Therefore, you must check
the underside of the floor tool at regular intervals.
Worn undersides of floor tools may have sharp edges
that can damage sensitive hard floors, such as parquet
or linoleum. The manufacturer does not accept any
responsibility for damage caused by worn floor tools.

Figure

Remove the upholstery nozzle and crevice nozzle
from the accessories holder as illustrated.

Figure

Vacuuming with accessories
Attach the nozzles to the suction pipe or handle as
required:

a)

Crevice nozzle for vacuuming crevices and corners,
etc.

b)

Upholstery nozzle for vacuuming upholstered
furniture, curtains, etc.

Figure

After use, push the crevice nozzle and upholstery
nozzle back into the accessories holder as indicated.

Turbo brush

If your vacuum cleaner is equipped with a turbo brush,
please consult the accompanying instruction manual
for notes on use and maintenance.

Figure

Pet hair tool
Floor tool for easy, thorough removal of pet hair
To clean the nozzle, simply vacuum it using the fixed
/ telescopic tube

Hard-floor brush

Figure

For vacuuming hard floor coverings (tiles, parquet
flooring, etc.)

Cleaning the hard-floor brush

Figure
a)

Vacuum from below to clean the brushes.

b)

Cut through threads and hairs wound round the
rollers using scissors.
Vacuum threads and hairs with the crevice nozzle.

17*

16*

15*

14

13*

12

11*

Figure

You can use the parking aid on the side of the
vacuum cleaner if you wish to stop vacuuming for a
short time.
Once you have switched off the vacuum cleaner,
slide the catch on the floor tool into the groove on
the side of the appliance.

Figure

The appliance can also be carried using one of the
two handles when vacuuming steps, for example.

When the work is done

Figure

Unplug the vacuum cleaner.
Tug the power cord briefly and let go. The cable then
rewinds automatically.

Figure

To store or transport the vacuum cleaner, use the
storage aid on the underside of the vacuum cleaner.
Stand the vacuum cleaner up on its end. Slide the
catch on the floor tool into the groove on the
underside of the appliance.

Changing the dust bag

Replacing the dust bag

Figure
a)

If the dust bag change indicator is completely yellow
when the floor tool is lifted from the floor and the
highest suction power is selected, the dust bag must
be changed. In this case it is essential to change the
dust bag due to the type of material it contains.
The nozzle, suction pipe and flexible tube
must not be blocked, as this would also
cause the dust bag change indicator to be
triggered.

b)

The handle can easily be detached from the hose to
remove blockages.

Figure

Open the lid by moving the locking lever in the
direction of the arrow.

Figure
a)

Seal the dust bag by pulling the sealing strip and
then remove it.

b)

Slide the new dust bag into the holder to the stop.

!

Caution: The lid only closes with a dust bag inserted.

24

23

22

21

20

19

18

*Depending on equipment
