36

Replacement parts and accessories

A

Replacement filter pack

Filter type G (BBZ41FG)
For best performance: Gplus (BBZ41GPLUS)

Contents:
4 filter bags with seal
1 micro-hygiene filter

http://

www.dust-bag-bosch.com

B Textile filters (permanent filters)

BBZ10TFG

Reusable bag with Velcro(R) fastener.

C Hepa filter

BBZ153HF

Additional filter for cleaner exhaust air.
Recommended for allergy sufferers. Replace once a
year.

D Micro-active carbon filter

BBZ192MAF

Combination of micro filter and active carbon filter.
Combats unpleasant odours. Replace twice a year.
Replace carbon filter frame with micro filter frame.

Please note!

It is not possible to combine a Hepa

filter and a Micro-active carbon filter.

E Bionic filter /

AirFresh System BBZ11BF

Additional filter for reducing unpleasant odours
Please replace the filter once it begins to lose its
effect (after approx. 1 year)
Reference number: 468637

F TURBO-UNIVERSAL

®

brush for upholstery

BBZ42TB

All in one brushing and vacuuming of upholstered
furniture, mattresses, car seats, etc. Especially suit-
able for picking up pet hair. The brush roller is dri-
ven by the suction air flow of the vacuum cleaner.
No separate electrical connection is needed.

G TURBO-UNIVERSAL

®

brush for floors

BBZ102TBB

All in one brushing and vacuuming of shallow pile
rugs and carpets and all hard floor coverings.
Especially suitable for picking up pet hair. The brush
roller is driven by the suction air flow of the vacuum
cleaner.
No separate electrical connection is needed.

H Hard-floor brush

BBZ123HD

For vacuuming hard floors (parquet flooring, tiles,
terracotta, etc.)

Before using for the first time

Figure

Open the dust bag compartment lid (see Fig. 23).
Remove the motor protection filter from the
appliance
Place the Bionic filter / AirFresh System onto the
motor protection filter.
Push the filter into the appliance and close the
dust bag compartment lid.

1*

Figure

Push the handle onto the flexible tube and until it
engages.

Figure

Push the crevice nozzle and upholstery nozzle back
into the accessories holder as indicated.

Setting up

Figure
a)

Push the flexible hose adapter into the air intake
opening on the vacuum cleaner lid until it engages.

b)

To remove the flexible hose, press the two lugs
together and pull the tube out.

Figure
a)

Connect the handle and the telescopic tube together.

b)

Push the handle into the telescopic tube until
it engages.
Press on the locking collar and pull out the
telescopic tube to disconnect.

Figure
a)

Connect the floor tool and the telescopic tube

together.

b)

Push the telescopic tube into the connecting piece of
the floor tool until it engages.
Press on the locking collar and pull out the
telescopic tube to disconnect.

Figure

To adjust the length of the telescopic tube, adjust
the adjusting sleeve/sliding switch in the direction of
the arrow and adjust the tube to the required length.

Figure

Holding the power cord by the plug, pull out the
required length and plug it into the mains socket.

Figure

Press the on/off button in the direction of the arrow
to switch your vacuum cleaner on/off.

Controlling the suction level

Figure
Adjust the suction by turning the on/off button in the
direction of the arrow.
The suction level can be infinitely adjusted to the level
required by turning the control knob in the direction of
the arrow.

Low power range

=>

For vacuuming delicate materials, e.g. delicate
upholstery, curtains, etc.
Medium power range

=>

For daily vacuuming of lightly soiled floors.
High power range

=>

For vacuuming durable floor coverings, hard floors
and surfaces with heavy deposits of dirt.

10

9

8

7*

6*

5*

4

3*

2*
