Cleaning the motor protection filter
The motor protection filter should be cleaned
regularly by knocking out the dirt and rinsing.
Figure
Open the dust bag compartment lid (see
Figure 18).
Pull out the motor protection filter in the
direction of the arrow.
Clean the motor protection filter by tapping it.
If it is very dirty, the motor protection filter
should be rinsed.
The filter must then be left to dry for at least
24 hours.
After cleaning, slide the motor protection filter
into the vacuum cleaner and close the dust
bag compartment lid.
Replacing the Hepa filter
If your vacuum cleaner is equipped with a Hepa
filter, this should be replaced once a year.
Figure
Open the dust compartment lid
(see Figure 18)
Remove the Hepa filter from the guide.
Insert the new Hepa filter into the vacuum
cleaner and close the lid.
Care
Always switch off the vacuum cleaner and
disconnect the power cord from the mains before
cleaning the appliance.
The vacuum cleaner and plastic accessories can
be cleaned with a commercial plastic cleaner.
!
Do not use a scourer, glass- cleaning agent or
multipurpose cleaning product.
Never immerse the vacuum cleaner in water.
If necessary, the dust compartment can be
cleaned with a second vacuum cleaner or simply
wiped with a dry cloth or dusting brush.
Subject to technical modifications.
31*
30*
en
Using dust bags
If necessary, a dust bag may be used instead of
the dust collector.
Figure
Open the vacuum cleaner lid (see Figure 18)
Remove the dust collector and insert a dust
bag.
Close the vacuum cleaner lid.
You have bought an extremely powerful device.
The highest suction setting is therefore only
recommended for heavily soiled, short-pile
carpets and hard floors.
The required suction power can be selected by
adjusting the suction regulator (see Figure 9).
Low suction range:
For vacuuming delicate fabrics, e.g. curtains.
Middle suction range:
For daily vacuuming of lightly soiled floors.
High suction range:
For vacuuming durable floor coverings, hard
floors and for heavily soiled surfaces.
Replacing the dust bag
Figure
If suction diminishes considerably, the dust
bag must be replaced, even if it is not yet full.
In this case it is essential to change the dust
bag due to the type of material it contains.
Turn the dust compartment locking lever in
the direction of the arrow to open the vacuum
cleaner lid.
Figure
Seal the dust bag by pulling the locking tab
and then remove it.
Figure
Place a new dust bag in the holder and close
the vacuum cleaner lid.
!
Caution: The dust bag compartment lid will
only close when the dust bag, textile filter
or dust collector are inserted.
