en

Figure

Holding the power cord by the plug, pull out
the required length and plug it into the mains
socket.

Figure

Press the on/off button in the direction of the
arrow to switch your vacuum cleaner on/off.

Figure

Adjust the suction by turning the on/off button
in the direction of the arrow.

Vacuuming

Figure

Adjusting the floor tool:

a)

Rugs and carpets

b)

Hard floors

Figure

Vacuuming using the accessories
(if required, connect them to the handle or the
suction pipe).

a)

Multi-purpose nozzle
For cleaning corners and crevices, as well as
upholstered furniture, curtains, etc.

b)

Crevice nozzle
For cleaning crevices and corners.

c)

Upholstery nozzle
For cleaning upholstered furniture, curtains,
etc.

d)

Matress nozzle
For cleaning mattresses, upholstery, etc.

e)

Hard-floor brush
For cleaning hard floor coverings (tiles,
parquet flooring, etc.)

f)

Hard furnishings brush
For cleaning window frames, cabinets,
mouldings, etc.

Figure

Secure the drill dust nozzle to the handle and
then place against the wall, so that the nozzle
drill hole opening sits directly over the hole to
be drilled.

Select the lowest power setting and then
switch on the vacuum cleaner.

12*

11*

10

9

8

7

Suction holds the drill dust nozzle in the
required position. Depending on the surface
of the wall to be drilled it may be necessary to
readjust the power to a higher setting to
ensure the drill dust nozzle is firmly attached.
Any fine particles are automatically vacuumed
up.

!

Caution: The drill dust nozzle should only
be used in conjunction with the dust
collector since fine drill dust can impair the
function of the dust bag.

Figure

You can use the parking aid on the back of
the vacuum cleaner if you wish to stop
vacuuming for a short time.
Slide the catch on the floor tool into the
groove at the rear of the appliance.

Figure

The appliance can also be carried using the
two handles when vacuuming steps, for
example.

When the work is done

Figure

Unplug the vacuum cleaner.
Tug the power cord briefly and let go. The
cable then rewinds automatically.

Figure

To store or transport the vacuum cleaner, use
the storage aid on the underside of the
vacuum cleaner.
Stand the vacuum cleaner up on its end. Slide
the catch on the floor tool into the groove on
the underside of the appliance.

You have purchased a floor vacuum cleaner
which can vacuum up any type of dry dirt using
the dust collector or dust bag.

We recommend that you use:
-  the dust collector, in particular for your

hobbies, e.g. to remove wood shavings, etc.

-  the dust bag principally for everyday

household cleaning.
