en

Disposal information

Packaging

The packaging is designed to protect the
vacuum cleaner from being damaged during
transportation.
It is made of environment-friendly materials
and therefore can be recycled.
Dispose of packaging which is no longer
required at recycling points.

Used vacuum cleaners

Used vacuum cleaners still contain many
recyclable materials.
Therefore, please take used vacuum cleaners
to your retailer or recycling centre so that they
can be recycled.
Please enquire about current disposal
methods at your retailer or local council.

!

Please note

The mains socket must be protected by a
16 amp fuse.
If a fuse is be tripped when you switch on the
vacuum cleaner, this may be because other
electrical appliances which have a high
current draw are connected to the same
power circuit.
To prevent the fuse from tripping, select the
lowest power setting before switching the
vacuum cleaner on, and increase the power
only once it is running.

Fold out picture pages.

Before using for the first time

Figure

Push the handle onto the flexible tube and
until it engages.

Setting up

Figure
a)

Push the hose connector into the opening on
the vacuum cleaner until it engages.

b)

To remove the flexible hose, press the two
lugs together and pull the hose out.

Figure
a)

Connect the handle and the suction pipe
together.

b)

Push the handle into the telescopic tube until
it engages. To release the connection, press
the release button and pull the handle out.

Figure
a)

Connect the floor tool and the suction pipe
together.

b)

Insert the telescopic tube into the floor tool
connector.

Figure
a)

Connect the suction pipes together.

b)

Disconnect the telescopic tube and adjust its
length by moving the adjusting button/sliding
sleeve in the direction of the arrow.

Figure

Attach the accessories holder to the multi-
purpose nozzle and clip it onto the suction
pipe/telescopic tube.

6*

5*

4*

3*

2

1*
