38

Vacuuming

!

 Caution

  Floor nozzles are subject to a certain amount of

wear, depending on the type of hard floors you have
(e.g. rough, rustic tiles). You must therefore check
the underside of the floor nozzle at regular inter vals.
Worn undersides of floor nozzles may have sharp
edges that can damage delicate hard floors, such as
parquet or linoleum. The manufacturer does not ac-
cept any responsibility for damage caused by worn
floor nozzles.

Fig.

8

Set the adjustable floor nozzle:

„

 Rugs and carpets ==>

„

 Hard floors/parquet ==>

If you are vacuuming up relatively large particles, make
sure that you vacuum them up successively and careful-
ly to ensure that the vacuum channel of the floor nozzle
does not become blocked.
If necessar y, you should raise the nozzle in order to
better vacuum up the dirt particles.

Vacuuming with accessories

Fig.

9*

Attach the nozzles to the suction pipe or handle as re-
quired:
a) Crevice nozzle for vacuuming crevices and corners,

etc.

b) Upholster y nozzle for vacuuming upholstered furni-

ture, curtains, etc.

c) Animal-hair nozzle

d) Hard-floor nozzle for vacuuming hard floor coverings

(tiles, parquet flooring, etc.)

Fig.

10

You can use the parking aid on the back of the vacuum
cleaner if you want to stop vacuuming for a short time.

•

After switching off the appliance, slide the hook on
the floor nozzle into the parking aid.

Fig.

11

When vacuuming stairs, the appliance must be positi-
oned at the bottom of the stairs. If it does not reach
far enough, the appliance can also be carried using the
carr ying handle.

After vacuuming

Fig.

12

•

Switch off the appliance.

•

Pull out the mains plug.

•

Briefly pull on the power cord and then let go. (The
power cord retracts automatically.)

Fig.

13*

•

Unlock the telescopic tube by moving the sliding
switch in the direction of the arrow, and slide one
tube into the other.

* Dependent on model

Fig.

14

To store the appliance, use the storage aid on the un-
derside.
a) Prop up the appliance on the hose or dust-container

handle.

b) Slide the hook on the floor nozzle into the storage

aid.

Disassembly

Fig.

15

•

To remove the suction hose, press the two catches
together and pull out the hose from the appliance's
suction opening.

Fig.

16*

a) Telescopic tube without accessor y connection:

   To release the connection, turn the handle slightly

and pull it out of the telescopic tube.

b) Telescopic tube with accessor y connection:

   To release the connection, press the locking collar

on the telescopic tube and and pull out the handle.

Fig.

17*

a) Nozzle without accessor y connection:

   To release the connection, turn the telescopic tube

slightly and pull it out of the floor nozzle.

b) Nozzle with accessor y connection:

   To release the connection, press the locking collar

and pull the telescopic tube out of the floor nozzle.

Cleaning & maintenance

Emptying the dust container

Fig.

18

In order to achieve the best possible vacuuming re-
sults, the dust container should be emptied after ever y
use or, at the latest, when dust in the dust container
has reached the marking at any point.

!

 Caution

   The dust container can only be removed when the

appliance is in a horizontal position. Therefore,
place the appliance on the floor to unlock the re-
lease button.

Fig.

19

a) Remove the dust container from the appliance by

pulling it upwards out of the cover.

b) Press on the upper catch to unlock the lid of the dust

container and empty the dust container.

c) Check the fluff filter and rinse it under running wa-

ter, if necessar y. Allow to dr y before putting it back
in the dust container. Close and lock the lid.

d) Insert the dust container into the appliance.
