42

* Depending on model

Figure

To store or transport the vacuum cleaner, use the storage
aid on the underside of the vacuum cleaner.
Stand the vacuum cleaner up on its end. Slide the catch
on the floor tool into the groove on the underside of the
vacuum cleaner.

Changing the dust bag and filters

Replacing the dust bag

Figure

If the dust bag change indicator lights up brightly and
evenly when the floor tool is lifted from the carpet and
the highest suction power is selected, the dust bag must
be changed, even though it may not yet be full. In this
case it is essential to change the dust bag due to the
type of material it contains.
First check that the nozzle, suction pipe and flexible hose
are not blocked, as this would also lead to the dust bag
change indicator being triggered.

Figure

Open the lid by moving the locking lever in the direction
of the arrow.

18

17

16

Figure
a)

Seal the dust bag by pulling the sealing strip and then
remove it.

b)

Insert a new dust bag into the holder and close the dust
bag compartment lid.

!

Caution: the lid will only close when the dust bag is
inserted.

Cleaning the motor protection filter

The motor protection filter should be cleaned regularly by
knocking out the dirt and rinsing.

Figure

䡲

Open the dust bag compartment lid (see Figure 18).

䡲

Pull out the motor protection filter in the direction of the
arrow.

䡲

Clean the motor protection filter by tapping it.

䡲

If it is very dirty, the motor protection filter should be
rinsed.
The filter must then be left to dry for at least 24 hours.

䡲

After cleaning, slide the motor protection filter into the
vacuum cleaner and close the dust bag compartment lid.

Cleaning the foam filter

If your appliance is fitted with a filter frame and foam
filter, the foam filter should be cleaned at regular
intervals by tapping out the dust or rinsing the filter.

20*

19

Figure

Open the dust bag compartment lid (see Fig. 18).
Pull out the filter frame and foam filter in the
direction of the arrow.
Remove the foam filter from the filter frame and
clean it by tapping out the dust.
If the foam filter is very dirty, it should be rinsed.
After rinsing it, allow the foam filter to dry for at
least 24 hours.
After cleaning, place the foam filter back in the filter
frame, insert the filter frame with foam filter in the
appliance and close the dust bag compartment lid.

!

Caution:

The vacuum cleaner must not be operated

without the motor protection filter.

21*

Replacing the HEPA filter (motor protection filter)

If your vacuum cleaner is equipped with a HEPA filter, this
should be replaced once a year.

Figure

䡲

Open the dust bag compartment lid.

䡲

Pull out the HEPA filter in the direction of the arrow and
remove it from the appliance.

䡲

Insert the new HEPA filter and close the dust bag
compartment lid.

Replacing the exhaust filter

You must replace the exhaust filter in your vacuum cleaner
once a year.

Replacing the micro-hygiene filter

Figure

䡲

Open the dust bag compartment lid (see Figure 18).

䡲

Release the filter holder by pressing the locking tab in the
direction of the arrow

䡲

Remove the foam filter and micro-hygiene filter.
Insert the new micro-hygiene filter and foam filter into the
filter holder.

䡲

Insert the filter holder into the vacuum cleaner and clip
into place.

Replacing the HEPA filter

You can order a new filter from our after-sales service
using the following replacement part number: 574 020

Figure

䡲

Open the dust bag compartment lid (see Figure 18).

䡲

Release the HEPA filter by pressing the locking tab in the
direction of the arrow and remove it from the vacuum
cleaner (see Figure 23).

䡲

Insert the new HEPA filter and clip into place.

If you have used the vacuum cleaner for fine dust parti-
cles (such as plaster or cement), clean the motor pro-
tection filter by tapping it and, if necessary, replace the
motor protection filter and the exhaust filter.

24*

23*

22*
