9

immediately to clean the blockage .
8 . When using the cleaner, don’t plug up the air outlet by
towel or other matters, otherwise the efficiency of dust ab-
sorbance will be influenced, and the motor will be at high
risk of being burnt out .
9 . Never use the cleaner at uneven floor or ground; and be
very careful when cleaning stairs to prevent the cleaner from
falling down .
10 . Never absorb live stumps with the cleaner, otherwise the
motor may be damaged .
11 . The cleaner should be kept far away from heat sources
(such as central heating, oven, etc) to avoid the distortion of
plastic parts as well as the influence caused by such distor-
tion .
12 . Before using the cleaner, please remove big and sharp
matters on the floor to avoid damaging the plastic parts, fil-
ter gauzes and motor .
13 . Never absorb water or other liquid with this cleaner, oth-
erwise, the motor will be damaged .
14 . This appliance is not intended for use by persons (includ-
ing children), with reduced physical, sensory or mental ca-
pabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use
of the appliance by a person responsible for their safety .

ASSEMBLY INSTRUCTIONS

1 . Before assembling the cleaner, please confirm all parts and
components for the cleaner are received by referring to Parts
and Components List .
2 . Please remember to cut off the power supply before as-
sembly .

ASSEMBLY OF HOSE

1 . As is shown in Figure (3), insert the hose into the duct inlet
of the machine body in horizontal direction . Please pay at-
tention to the alignment of two projecting parts . Turn the
hose right when it is pushed into the bottom, a click of in-
serting sound may be heard, i .e . the hose is assembled into
the machine body completely .

ASSEMBLY AND REMOVAL OF DUST BARREL

As is shown in Figure (4), place the bottom of the dust barrel
on the projecting part at the front end of the machine body,
and press down the dust barrel . When the front-end hook
is entered into the corresponding part of the machine body
completely, and a click of inserting sound is heard, which in-
dicate that the dust barrel is assembled in place . To remove
the dust barrel, press down the handle of the dust barrel;
when the handle is pressed down to the bottom, the dust
barrel can be lifted to remove .

ASSEMBLY OF METAL EXTENSION PIPE AND

FLOOR BRUSH

Insert the front end of the hose handle into the metal exten-
sion pipe according to Figure (5); then insert the other end of
the metal extension pipe into the rounded inlet of the floor
brush, and adjust to the proper direction . At this time, the
assembly of the whole machine is completed .

OPERATION INSTRUCTIONS

HOW TO START

1 . First of all, pull out the power cord from the cord reel to the
needed length; insert the power cord plug into the power
socket, and press down the power switch button with finger
or step on it with foot; then you can control the start and

stop of the cleaner .
2 . The yellow mark on the power cord indicates its desired
length . Never pull out the power cord to the length exceed-
ing the red mark .

CONTROL OF SUCTION FORCE

When the suction inlet is jammed by some cloth due to the
over-large suction force, you can adjust the air escape push-
button on the hose handle to control the suction force at the
suction inlet, as is shown in Figure (6) .

PROTECTIVE DEVICES OF MOTOR

1 . There is a temperature controller designed in the body of
cleaner motor, which can automatically cut off the power
supply of motor to prevent overheating . When the air-inlet
or air-outlet pipe is overloaded or blocked, the temperature
of motor rises, then the temperature controller cuts off the
power supply of motor automatically to make the motor
cool, preventing the cleaner from being damaged .
2 . If the temperature controller is cut off, stop the cleaner im-
mediately and pull out the power plug to make the cleaner
cool, and check and remove the hair roll or other roll-like rub-
bish blocking the air inlet (including the hose and the spile),
and replace the filter HEPA or filter gauze when necessary .
3 . After cooling the motor for 30mins, plug in the power plug
and check whether the temperature controller has been re-
set . If the power supply of the cleaner hasn’t been cut off,
the temperature controller of the motor won’t be reset even
when the motor has become cool .

MAINTENANCE OF THE CLEANER

All the day-to-day maintenance and repair jobs should be
done after the power plug has been pulled out .
1 . Frequently remove the rubbish from the dust barrel, so as
to avoid the failure of the cleaner .
2 . Never wipe the surface of the cleaner with gasoline or oily
liquid . Wipe it with water or neutral detergent . Caution: be
sure to wring out the wiping cloth dry for wiping, it is pro-
hibited for water to infiltrate into electrical elements of the
cleaner .
3 . When the cleaner is placed idle not in use, it should not be
put directly in the sun or in a damp place .

STORAGE OF THE CLEANER

1 . Upon the completion of the operation of the cleaner, turn
off its power supply, and pull the power plug out of the pow-
er socket, then step on the cord reeling button to reel in the
power cord fully . Hang the floor brush onto the floor brush
hook, as is shown in Figure (7) .
1 . Place the cleaner in the dry indoor environment .

CLEANING OF THE DUST BARREL

Remove the rubbish in the dust barrel frequently to avoid
the failure of the cleaner .
1 . Clean the dust barrel only after the power plug of the
cleaner has been pulled out;
2 . Put the dust barrel over the rubbish bin (bag), press down
the releasing button of the dust barrel, the bottom cover of
the dust barrel will automatically fall down, and clear and
empty the dust barrel, as is shown in Figure (8) .
CLEANING OF FRONT FILTER FOR MOTOR:
Warning: please make sure the power supply of the cleaner
has been cut off before carrying out the following steps:
1 . Pull out the power cord plug of the cleaner from the power
