Specifications

Main unit

Power supply

AC100-240 V, 50 Hz/60 Hz

Power consumption

300 W
6W when Standby mode set to Normal, 0.5W when Standby mode set to Eco*

1

* Operating Temperature: 25°C (77°F), Altitude: 700m (2,297 ft), IEC62087: 2008 Broadcast contents,

Picture mode: Dynamic

BTU value

Max 1,024BTU

LCD panel

Panel size

15.0 mm (0.59 inches) diagonal (16:10 aspect ratio)

Display method

Translucent screen LCD panel 3 panels, 3 primary color system

Pixels

1,024,000 (1280 pixels x 800 dots) x 3 panels

Colors

Full color (16,777,216 colors)

Lens

Fixed focus
Manual focus: F = 1.8, f = 6.08 mm

Throw ratio

0.46:1

Light source

230 W  UHM lamp

Lamp replacement cycle

Normal: 10,000hrs / Eco: 20,000hrs / Quiet: 10,000hrs

Light output*

2

3,300 lm
(When [PICTURE MODE] is set to [DYNAMIC], [LAMP POWER] is set to [NORMAL], [AUTO POWER SAVE] is set to [OFF],
and [DAYLIGHT VIEW] is set to [OFF])

Filter replacement cycle*

3

Normal: 5,000hrs / Eco: 6,000hrs / Quiet: 10,000hrs

Center-to-corner uniformity*

2

85%

Resolution

1280 x 800 pixels (Input signals that exceed this resolution will be converted to 1280 x 800 pixels.)

Contrast ratio*

2

20,000:1
(When [PICTURE MODE] is set to [DYNAMIC], [LAMP POWER] is set to [NORMAL], [IRIS] is set to [ON],
[AUTO POWER SAVE] is set to [OFF], and [DAYLIGHT VIEW] is set to [OFF])

Screen size

1.27-2.54 m (50-100 inches) diagonally, 16:10 aspect ratio

Installation

[FRONT/DESK], [FRONT/CEILING], [REAR/DESK], [REAR/CEILING]

Keystone correction range

Vertical:±15 ° (Auto, Manual), Horizontal:±15 ° (Manual)

Compatible signals

Video signal

Horizontal : 15.73 kHz, Vertical : 59.94 Hz
Horizontal : 15.63 kHz, Vertical : 50.00 Hz

Y/C signal

Horizontal : 15.73 kHz, Vertical : 59.94 Hz
Horizontal : 15.63 kHz, Vertical : 50.00 Hz

RGB signal

Displayable resolution: 640 x 400 to 1920 x 1200
Dot clock frequency: 162 MHz or less

YC

B

C

R

/YP

B

P

R

 signal

Displayable resolution: 480i/576i to 1920 x 1080
Dot clock frequency: 148.5 MHz or less

HDMI signal

Displayable resolution for movie-based signals: 480i/576i* to 1920 x 1080
Displayable resolution for still image signals: 640 x 400 to 1920 x 1200 (non-interlaced)
*Pixel-Repetition signal (dot clock frequency 27.0 MHz) only
Dot clock frequency: 25 MHz to 162 MHz

Terminals

COMPUTER 1 IN

1 (High-density D-sub 15 pin female)

R, G, B

0.7 V [p-p] 75 Ω


HD/SYNC TTL high impedance, automatic positive/negative polarity compatible

VD TTL high impedance, automatic positive/negative polarity compatible

(HD/SYNC and VD do not support 3 value SYNC.)

Y, P

B

 (C

B

), P

R

 (C

R

)

Y: 1.0 V [p-p] including synchronization signal, P

B

 (C

B

), P

R

 (C

R

): 0.7 V [p-p] 75 Ω

Y/C signal

Y: 1.0 V [p-p] C: 0.286 V [p-p] 75 Ω S1 signal compatible

COMPUTER 2 IN/
COMPUTER 1 OUT

1 (High-density D-sub 15 pin female)

R, G, B

0.7 V [p-p] 75 Ω


HD/SYNC TTL high impedance, automatic positive/negative polarity compatible

VD TTL high impedance, automatic positive/negative polarity compatible

(HD/SYNC and VD do not support 3 value SYNC.)

Y, P

B

 (C

B

), P

R

 (C

R

)

Y: 1.0 V [p-p] including synchronization signal, P

B

 (C

B

), P

R

 (C

R

): 0.7 V [p-p] 75 Ω

VIDEO IN

1 (Pin jack 1.0 V [p-p] 75 Ω

HDMI IN

2 (HDMI 19 pin, HDCP and Deep color compatible)

Audio signal

Linear PCM (Sampling frequency: 48 kHz/44.1 kHz/32 kHz)

AUDIO IN 1

1 (M3 stereo mini jack, 0.5 V [rms], input impedance 22 kΩ and more)

AUDIO IN 2

1 (Pin jack x 2 (L-R), 0.5 V [rms], input impedance 22 kΩ and more)

AUDIO OUT

1 (M3 stereo mini jack, stereo monitor output compatible,


0 V [rms] to 2.0 V [rms] variable, output impedance 2.2 kΩ and less)

PT-TW381R

LCD Projectors

As of A pril  2 02 0

1 / 8

TW381RG_STR_01_30/04/2020
