23

Care and maintenance

Shutting off the water and electricity supplies

•  Turn off the water tap after every wash cycle to avoid leaks.
•  Always  unplug  the  appliance  when  cleaning  it  and  when

performing maintenance work.

Cleaning the dishwasher

•  The  external  surfaces  of  the  machine  and  the  control  panel

can be cleaned using a non-abrasive cloth which has been
dampened with water. Do not use solvents or abrasive products.

•  Any marks on the inside of the appliance may be removed using

a cloth dampened with water and a little vinegar.

Preventing unpleasant odours

•  Always  keep  the  door  of  the  appliance  ajar  in  order  to  avoid

moisture from forming and being trapped inside the machine.

•  Clean  the  seals  around  the  door  and  detergent  dispensers

regularly using a damp sponge. This will avoid food becoming
trapped in the seals, which is the main cause behind the
formation of unpleasant odours.

Cleaning the spray arms

Food  residue  may  become  encrusted  onto  the  spray  arms
and block the holes used to spray the water. It is therefore
recommended that you check the arms from time to time and clean
them with a small non-metallic brush.
The two spray arms may both be removed.

To remove the upper spray arm, turn
the plastic locking ring in an anti-
clockwise  direction. The upper spray
arm should be replaced so that the
side with the greater number of holes
is facing upwards.

The lower spray arm can be removed
by pressing on the side tabs and
pulling it upwards.

Cleaning the water inlet hose

If the water hoses are new or have not been used for an extended
period of time, let the water run to make sure it is clear and free
of impurities before performing the necessary connections. If this
precaution is not taken, the water inlet could become blocked and
damage the dishwasher.

Clean the water inlet filter at the tap outlet regularly.

- Turn off the water tap.
-  Unscrew  the  end  of  the  water  inlet  hose,  remove  the  filter  and
clean it carefully under running water.
- Re-place the filter and screw the water hose back into position.

Cleaning the filters

The filter assembly consists of three filters which remove food
residues from the washing water and then recirculate the water.
They must be cleaned if you wish to achieve the best results in
every wash.

Clean the filters regularly.

The dishwasher must not be used without filters or if the filter

is loose.

• After several washes, check the filter assembly and if necessary
clean it thoroughly under running water, using a non-metallic brush
and following the instructions below:

1.

 Turn the cylindrical filter

C

 in an anti-clockwise direction and

pull it out

(fig. 1).

2.

 Remove the cup filter

B

 by exerting a slight pressure on the

side flaps

(fig. 2);

3.

 Slide out the stainless-steel plate filter

A

.

(fig. 3).

4.

 Inspect the trap and remove any food residues.

NEVER

REMOVE

 the wash-cycle pump protection

(black detail) (fig.4).

After cleaning the filters, re-place the filter assembly and fix it in
position correctly; this is essential for maintaining the efficient
operation of the dishwasher.

Leaving the machine unused for extended

periods

•  Disconnect the appliance from the electricity supply and shut

off the water tap.

•  Leave the door of the appliance ajar.

•  When  you  return,  run  a  wash  cycle  when  the  dishwasher  is

empty.
