18

For natural gas connection;

United kingdom type gas connection:

WARNING:

The gas hose must not be clamped, bent ar trapped or come

into contact  with hat parts of the product. There is the risk of explosion
due to damaged gas hose.

Ventilation Of Room

The air needed for burning is received from room air and the gases emitted

are given directly in room. For safe operation of your product, good room
ventilation is a precondition. If no window or room to be utilized for room
ventilation is available, additional ventilation should be installed. However,
room has a door opening outside, it is no needed to vent holes.

Room Size

Ventilating Opening

Smaller than 5 m³

min. 100 cm²

Between 5 m³ - 10 m³

min. 50 cm²

Bigger than 10 m³

no need

In basement or cellar

min. 65 cm²

Main Gas Pipe

Gasket
Nut

Natural Gas
Connection Hose

WARNING:

Natural gas connection should

be done by authorized service.
For natural gas connection, place gasket
in the nut at the edge of natural gas connection
hose. To install the hose on main gas pipe,
turn the nut. Complete the connection by
making gas leakage control.

77l

6

5

/

r

4

F

rn

2

c, __ _

1. Gasket
2. Adapter
3. Gas (safety) hose
4. Valve with 90

°

 outlet

5. Connection piece
6. Gas supply pipe

GB
