5

considered when undertaking any installation. Failure to install the appliance
correctly will render the warranty null and void.

Range cookers are heavy and should be handled by two people. Never lift or drag a
range by the oven handles as damage may occur.

Note: Pictures and graphics in this manual cover different models and may vary in
minor details from your cooker.

INSTALLING RANGE COOKER

Rating of Services          The rating plate is visible in the storage area of the cooker and a copy is also

attached to page two of the user manual.
Before connecting the cooker, check that the requirements on the rating plate
correspond with those of the electrical system and gas supply (where applicable).
Ensure that the electrical system and isolating switches have a suitable capacity to
carry the maximum power as indicated on the rating plate.This chart can be used as
a guide to the electrical supply ratings.

Table N°1

Cooker model

Type

MCB size for dedicated
cooker circuit

The cable of
alimentation

  60 cm single oven

Gas hob top

13 AMP MCB

H05RR-F or H05VV-F
3X1,5

 mm²

 *60 cm single oven

Induction hob top

32 AMP MCB

H07RN-F  3X4

mm²

  60 cm single gas oven

Gas hob top

13 AMP MCB

H05RR-F or H05VV-F
3X1,5

 mm²

  90 cm single hybrid oven

Gas hob top

16 AMP MCB

H05RR-F or H05VV-F
3X1,5

 mm²

  90 cm single gas oven

Gas hob top

13 AMP MCB

H05RR-F or H05VV-F
3X1,5

 mm²

  90 cm single oven

Gas hob top

16 AMP MCB

H05RR-F or H05VV-F
3X1,5

 mm²

*90 cm single oven

Induction hob top

32 AMP MCB

H07RN-F  3X4

mm²

  90 cm twin oven

Gas hob top

20 AMP MCB

H05BB-F or H05SS-F
3X2,5

 mm²

 *90 cm twin oven

Induction hob top

32 AMP MCB

H07RN-F  3X4

mm²

 100 cm twin oven

Gas hob top

20 AMP MCB

H05BB-F or H05SS-F
3X2,5

 mm²

*100 cm twin oven

Induction hob top

32 AMP MCB

H07RN-F  3X4

mm²

 100 cm XG (3 oven compartments)   Gas hob top

32 AMP MCB

H07RN-F  3X4

mm²

*100 cm XG (3 oven compartments)   Induction hob top

40 AMP MCB

H07RN-F  3X6

mm²

 120cm twin oven

Gas hob top + griddle

32 AMP MCB

H07RN-F  3X4

mm²

*

With diversity factor applied

Positioning                     The cooker may be installed in a kitchen or open-plan kitchen diner but not in a

room containing a bath or shower. The cooker should be positioned in an area with
good light and free from draughts.
Any shelf or unit of combustible material should be at least 660mm above the
hotplate. In addition an area of 75mm wide on either side and behind the hotplate
must be clear of any combustible materials to a height of 400mm. Units must not
overhang over the hob.
Kitchen cabinets may be fitted flush to the sides of the cooker, but to allow for
cleaning and servicing
It is recommended that a 2.5mm gap be allowed on each side so that the cooker
may be moved if necessary.
The worktop or kitchen cabinets must not protrude beyond the height of the cooker
hotplate frame.

Ventilation                      Your appliance is not connected to a combustion products evacuation device. Th

e room in which it is to be installed must have an air supply in accordance with
national standards. The room must have an opening window or equivalent, and
some rooms may require a permanent vent in addition to the opening window.
General guidelines: The cooker must not be installed in a bedsit room of 20m³  or
