ENGLISH

en

13

When sawing, never remove the machine

from the material with the saw blade turning.

Allow the saw blade to come to a standstill.

If the saw blade blocks, turn the machine off

immediately.

Sawing along a straight line:

the cutting indicator

is used here (11). The left notch (marked 0°)

indicates the direction of the cut if the saw blade is

held vertically. The right notch (marked 45°)

indicates the direction of the cut if the saw blade is

held at 45°.

Sawing along a rail secured on the workpiece

:

In order to achieve an exact cutting edge, you can

attach a rail to the workpiece and then guide the

hand-held circular saw along this rail by means of

the guide plate (16).

Sawing with parallel guide:

For cuts parallel to a straight edge. The parallel

guide (12) can be inserted from either side into the

support provided for it. Tighten the locking screw

(8). It is best to calculate the exact cut width by

making a test cut.

Sawing with guide rail:

For dead straight, tear-free cutting edges with

millimetre precision. The anti-slip coating keeps the

surface safe and protects the workpiece against

scratches.

Saws with mitre rail system:

The machine is prepared for accommodation by the

Metabo mitre rail system. This permits particularly

comfortable mitre cuts of different angles.

Changing saw blades

Pull the plug out of the plug socket before any

adjustments or servicing are performed.

Press in the spindle locking button (27) and hold in

place. Turn the saw spindle slowly with the hexagon

wrench in the saw blade fixing screw (21) until the

lock catches.
Unscrew the saw blade fixing screw (21) gin a

clockwise direction and remove the outer saw blade

flange (22).
Pull back the movable safety guard (26) using the

lever (24) and remove the saw blade (23).
The contact areas between the inner saw blade

flange (25), the saw blade (23), the outer saw blade

flange (22) and the saw blade fixing screw (21) must

be clean.

Ensure that the inner saw blade flange (25) is

inserted in the right way: The inner saw blade

flange (25) has 2 sides, diameter 30 mm and 5/8“

(15.88 mm). Ensure a precise fit of saw blade

mounting hole to the inner saw blade flange (25)!

Incorrectly installed saw blades do not run smoothly

and lead to loss of control.
Insert a new saw blade, Make sure the direction of

rotation is correct. The direction of rotation is

indicated by arrows on the saw blade and guard.

Put on the outer saw blade flange (22).

Tighten the saw blade fixing screw (21) using the

(17) hexagon wrench.

Use only sharp, undamaged saw blades. Do

not use saw blades that are cracked or that

have changed their shape.

Do not use any saw blades made from high-

alloy high-speed steel (HSS).
Do not use any saw blades which do not

conform to the specified rating.

Use only saw blades with a diameter according to

the markings on the saw.

The saw blade must be suitable for the no-load

speed.
Use a saw blade that is suitable for the

material being sawn.
Use only genuine Metabo - saw blades. Saw

blades intended for cutting wood or similar

materials have to conform to EN 847-1.

Dust deposits must be regularly removed from the

machine. This includes vacuum cleaning the

ventilation louvres on the motor. Make sure that the

safety appliances, e.g. the movable guard, are in

perfect working order. The movable guard must

move freely, automatically, easily and exactly back

into its end position.

Switching on the machine briefly reduces the

voltage. Unfavourable mains power conditions may

have a detrimental effect on other machines. Power

impedances less than 0.3 ohm should not cause

malfunctions.

Use only genuine Metabo accessories.
Use only accessories that fulfil the requirements

and specifications listed in these operating

instructions.
For the complete range of accessories, see

www.metabo.com or the main catalogue.

Repairs to electrical tools must only be carried

out by qualified electricians!

A defective mains cable must be replaced only with

a special, original mains cable from Metabo

available from the Metabo service.
Contact your local Metabo representative if you

have Metabo power tools requiring repairs. For

addresses see www.metabo.com.
You can download a list of spare parts from

www.metabo.com.

8. Maintenance

9. Cleaning

10. Troubleshooting

11. Accessories

12. Repairs
