ENGLISH

en

12

Collect the particles generated at the source, avoid

deposits in the surrounding area.
Use suitable accessories for special work. In this

way, fewer particles enter the environment in an

uncontrolled manner.
Use a suitable extraction unit.
Reduce dust exposure with the following measures:

- do not direct the escaping particles and the

exhaust air stream towards yourself or nearby

persons or towards dust deposits,

- use an extraction unit and/or air purifiers,

- ensure good ventilation of the workplace and keep

it clean using a vacuum cleaner. Sweeping or

blowing stirs up dust.

- Vacuum or wash protective clothing. Do not blow,

beat or brush protective gear.

See page 2.

1 Connector (extraction connection piece / chip

ejection)

2 Handle

3 Trigger

4 Locking button

5 Side handle

6 Undercut limit stop (increases the max.

diagonal cut angle from 45° to 47°)

7 Scale (diagonal cut angle)

8 Locking screw (parallel guide)

9 2 Locking screws (diagonal cuts)

10 Marking (saw blade outer diameter)

11 Cutting indicator

12 Parallel stop

13 Marking (for reading off the scale on the parallel

guide)

14 Guide grooves to place the machines on guide

tracks from different manufacturers

15 Adjusting screw (adjust saw disc angle)

16 Guide plate

17 Hexagon wrench

18 Storage for hexagon wrench

19 Locking screw (depth of cut)

20 Scale (depth of cut)

21 Saw blade fixing screw

22 Outer saw blade flange

23 Saw blade

24 Lever (for swivelling back the movable guard)

25 Inner saw blade flange

26 Movable safety guard

27 Spindle locking button

Before commissioning, check that the rated

mains voltage and mains frequency stated on

the type plate match your power supply.

Always install an RCD with a maximum trip

current of 30 mA upstream.
Pull the plug out of the plug socket before any

adjustments or servicing are performed.

6.1 Setting cutting depth

Loosen the locking screw (19). Raise or lower the

motor section against the guide plate (16). Read the

depth of cut that has been set from the scale (20).

Tighten the locking screw (19) again.
It is advisable to set the depth of cut in such a way

that no more than half of each tooth on the saw

blade juts out under the workpiece. See illustration

on page 2.

Note:

 The clamping power of the locking screw (19)

can be adjusted. Unscrew the screw on the lever to

do this. Remove lever and mount offset

anticlockwise. Secure with screw. Ensure that

cutting depth adjustment moves freely when the

lever is open.

6.2 Slanting saw blade for diagonal cuts

Loosen the locking screws (9). Tilt the motor section

against the guide plate (16). Read the angle which

has been set from the scale (7). Tighten the locking

screws (9) again.
For a diagonal cut angle of 47°, push down the

undercut limit stop (6).

6.3 Correcting the saw disc angle

If, at 0°, the saw blade is not at right angles to the

guide plate: use the adjustment screw (15) to

correct the saw blade angle.

6.4 Setting extraction nozzle / chip ejection

The nozzle (1) can be rotated to the desired position

to extract or eject chips. To do this, push the nozzle

in up to the stop, turn and pull out again. The nozzle

can be locked in 45° increments so that it cannot

turn.
Sawdust extraction

To extract the sawdust, connect a suitable

extraction unit with suction hose to the machine.

7.1 Switching on and off

Switching on:

Push the locking button (4) forwards

and hold, then actuate the trigger (3).

Switching off:

 Release the trigger switch (3).

7.2 Working Directions

Lay out the mains cable such that the cut can be

executed without obstruction.
The marking (10) on the upper guide plate assists

you in positioning the saw on the workpiece and

when sawing. In the case of maximum cutting

depth, it marks approximately the outside diameter

of the saw blade and thus the cutting edge.

Do not switch the machine on or off while the

saw blade is touching the workpiece.
Let the saw blade reach its full speed before

making a cut.

When the hand-held circular saw is added, the

movable guard is swung backwards by the

workpiece.

5. Overview

6. Initial Operation, Setting

7. Use
