ENGLISH

en

10

Original instructions

We declare and accept sole responsibility for

ensuring: these circular saws identified by their type

and serial number *1) conform to all relevant

provisions of the directives *2) and standards *3).

Technical documents for *4) - see page 3.

This machine is suitable for sawing wood, plastics

and other similar materials.
The machine is not designed for plunge cuts.
KS 66 FS is suited for working with Metabo guide

rails and the Metabo mitre rail system.
The user bears sole responsibility for any damage

caused by inappropriate use.
Generally accepted accident prevention

regulations and the enclosed safety information

must be observed.

For your own protection and for the

protection of your power tool, pay

attention to all parts of the text that are

marked with this symbol!

WARNING

 – Read the operating

instructions to reduce the risk of injury.

WARNING – Read all safety warnings,

instructions, illustrations and

specifications provided with this power tool.

Failure to follow all instructions listed below may

result in electric shock, fire and/or serious injury.

Keep all safety instructions and information for

future reference.

Always include these documents when passing on

your power tool.

4.1 Sawing procedure

a)

DANGER: Keep hands away from

cutting area and the blade. Keep your

second hand on auxiliary handle, or motor

housing.

 If both hands are holding the saw, they

cannot be cut by the blade.
b)

Do not reach underneath the workpiece.

 The

guard cannot protect you from the blade below the

workpiece.
c)

Adjust the cutting depth to the thickness of

the workpiece.

 Less than a full tooth of the blade

teeth should be visible below the workpiece.
d)

Never hold the workpiece in your hands or

across your leg while cutting. Secure the

workpiece to a stable platform.

 It is important to

support the work properly to minimise body

exposure, blade binding, or loss of control.
e)

Hold the power tool by the insulated gripping

surfaces when performing an operation where

the cutting accessory may contact hidden

wiring or its own cord.

 Contact with a "live" wire

will also make exposed metal parts of the power tool

"live" and could give the operator an electric shock.
f)

When ripping, always use a rip fence or

straight edge guide.

 This improves the accuracy

of cut and reduces the chance of blade binding.
g)

Always use blades with correct size and

shape (diamond versus round) of arbour holes.

Blades that do not match the mounting hardware of

the saw will run off-centre, causing loss of control.
h)

Never use damaged or incorrect blade

washers or bolt.

The blade washers and bolt were

specially designed for your saw, for optimum

performance and safety of operation.

4.2 Kickback causes and related warnings

- kickback is a sudden reaction to a pinched,

jammed or misaligned saw blade, causing an

uncontrolled saw to lift up and out of the workpiece

toward the operator;

- When the blade is pinched or jammed tightly by

the kerf closing down, the blade stalls and the

motor reaction drives the unit rapidly back toward

the operator.

- If the blade becomes twisted or misaligned in the

cut, the teeth at the back edge of the blade can dig

into the top surface of the wood causing the blade

to climb out of the kerf and jump back toward the

operator.

Kickback is the result of saw misuse and/or

incorrect operating procedures or conditions  and

can be avoided by taking proper precautions as

given below.
a)

Maintain a firm grip with both hands on the

saw and position your arms to resist kickback

forces. Position your body to either side of the

blade, but not in line with the blade.

 Kickback

could cause the saw to jump backwards, but

kickback forces can be controlled by the operator, if

proper precautions are taken.
b)

When blade is binding, or when interrupting

a cut for any reason, release the trigger and

hold the saw motionless in the material until

the blade comes to a complete stop. Never

attempt to remove the saw from the work or

pull the saw backward while the blade is in

motion or kickback may occur.

 Investigate and

take corrective actions to eliminate the cause of

blade binding.
c)

When restarting a saw in the workpiece,

centre the saw blade in the kerf so that the saw

teeth are not engaged into the material.

 If a saw

blade binds, it may walk up or kickback from the

workpiece as the saw is restarted.
d)

Support large panels to minimise the risk of

blade pinching and kickback.

 Large panels tend

1. Declaration of Conformity

2. Specified Conditions of Use

3. General Safety Information

4. Special Safety Instructions
