8

32.

Only use the saw blade with the diameter that is
marked on the tool or specified in the manual.

 Use

of an incorrectly sized blade may affect the proper
guarding of the blade or guard operation which could
result in serious personal injury.

33.

Keep blade sharp and clean.

 Gum and wood pitch

hardened on blades slows saw and increases
potential for kickback. Keep blade clean by first
removing it from tool, then cleaning it with gum and
pitch remover, hot water or kerosene. Never use
gasoline.

34.

Wear a dust mask and hearing protection when
use the tool.

SAVE THESE INSTRUCTIONS.

 WARNING:

DO NOT let comfort or familiarity with product (gained
from repeated use) replace strict adherence to safety
rules for the subject product. MISUSE or failure to
follow the safety rules stated in this instruction
manual may cause serious personal injury.

FUNCTIONAL DESCRIPTION

 CAUTION:

• Always be sure that the tool is switched off and

unplugged before adjusting or checking function on the
tool.

Adjusting depth of cut

 CAUTION:

• After adjusting the depth of cut, always tighten the lever

securely.

(Fig. 8)

Loosen the lever on the depth guide and move the base
up or down. At the desired depth of cut, secure the base
by tightening the lever.
For cleaner, safer cuts, set cut depth so that no more than
one blade tooth projects below workpiece. Using proper
cut depth helps to reduce potential for dangerous
KICKBACKS which can cause personal injury.

Bevel cutting (Fig. 9 & 10)

Loosen the clamping screws. Set for the desired angle
(0°- 45°) by tilting accordingly, then tighten the clamping
screws securely.

Sighting (Fig. 11)

For straight cuts, align the 0° position on the front of the
base with your cutting line. For 45° bevel cuts, align the
45° position with it.

Switch action

 CAUTION:

• Before plugging in the tool, always check to see that

the switch trigger actuates properly and returns to the
“OFF” position when released.

• Do not pull the switch trigger hard without pressing in

the lock-off button. This can cause switch breakage.

(Fig. 12)

To prevent the switch trigger from being accidentally
pulled, a lock-off button is provided.

To start the tool, depress the lock-off button and pull the
switch trigger. Release the switch trigger to stop.

 WARNING:

• For your safety, this tool is equipped with a lock-off

button which prevents the tool from unintended
starting. NEVER use the tool if it runs when you simply
pull the switch trigger without pressing the lock-off
button. Return tool to a Makita service center for proper
repairs BEFORE further usage.

• NEVER tape down or defeat purpose and function of

lock-off button.

ASSEMBLY

 CAUTION:

• Always be sure that the tool is switched off and

unplugged before adjusting or checking function on the
tool.

Removing or installing saw blade

 CAUTION:

• Be sure the blade is installed with teeth pointing up at

the front of the tool.

• Use only the Makita wrench to install or remove the

blade.

To remove the blade, press the shaft lock so that the
blade cannot revolve and use the wrench to loosen the
hex bolt counterclockwise. Then remove the hex bolt,
outer flange and blade.

(Fig. 13)

When changing blade, make sure to also clean upper and
lower blade guards of accumulated sawdust. Such efforts
do not, however, replace the need to check lower guard
operation before each use.

(Fig. 14)

For tool with the inner flange for other than 15.88 mm
hole-diameter saw blade (Fig. 15)

The inner flange has a certain diameter protrusion on one
side of it and a different diameter protrusion on the other
side. Choose a correct side on which protrusion fits into
the saw blade hole perfectly.
Next, mount the inner flange onto the mounting shaft so
that the correct side of protrusion on the inner flange
faces outward and then place saw blade and outer flange.
BE SURE TO TIGHTEN THE HEX BOLT CLOCKWISE
SECURELY.

 CAUTION:

•

Make sure that the protrusion “a” on the inner
flange that is positioned outside fits into the saw
blade hole “a” perfectly.

Mounting the blade on the

wrong side can result in the dangerous vibration.

For tool with the inner flange for a 15.88 mm hole-
diameter saw blade (country specific) (Fig. 16 & 17)

Mount the inner flange with its recessed side facing
outward onto the mounting shaft and then place saw
blade (with the ring attached if needed), outer flange and
hex bolt.
BE SURE TO TIGHTEN THE HEX BOLT CLOCKWISE
SECURELY.

 WARNING:

•

Before mounting the blade onto the spindle, always
be sure that the correct ring for the blade’s arbor
hole you intend to use is installed between the
