6

ENGLISH (Original instructions)

Explanation of general view

SPECIFICATIONS

• Due to our continuing program of research and development, the specifications herein are subject to change without

notice.

• Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2003

Intended use

ENE078-2

The tool is intended for performing lengthways and
crossways straight cuts and mitre cuts with angles in
wood while in firm contact with the workpiece. With
appropriate Makita genuine saw blades, other materials
can also be sawed.

Power supply

ENF002-2

The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and can
only be operated on single-phase AC supply. They are
double-insulated and can, therefore, also be used from
sockets without earth wire.

General Power Tool Safety

Warnings

GEA010-1

 WARNING Read all safety warnings and all

instructions.

 Failure to follow the warnings and

instructions may result in electric shock, fire and/or
serious injury.

Save all warnings and

instructions for future reference.

CIRCULAR SAW SAFETY

WARNINGS

GEB013-7

Cutting procedures

1.

 DANGER: Keep hands away from cutting area

and the blade. Keep your second hand on

auxiliary handle, or motor housing.

 If both hands

are holding the saw, they cannot be cut by the blade.

2.

Do not reach underneath the workpiece.

 The guard

cannot protect you from the blade below the
workpiece.

3.

Adjust the cutting depth to the thickness of the
workpiece.

 Less than a full tooth of the blade teeth

should be visible below the workpiece.

4.

Never hold piece being cut in your hands or
across your leg. Secure the workpiece to a stable
platform.

 It is important to support the work properly

to minimize body exposure, blade binding, or loss of
control.

A typical illustration of proper hand support,
workpiece support, and supply cord routing (if
applicable). (Fig. 1)

5.

Hold the power tool by insulated gripping surfaces
only, when performing an operation where the
cutting tool may contact hidden wiring or its own
cord.

 Contact with a “live” wire will also make exposed

metal parts of the power tool “live” and could give the
operator an electric shock.

6.

When ripping, always use a rip fence or straight
edge guide.

 This improves the accuracy of cut and

reduces the chance of blade binding.

7.

Always use blades with correct size and shape
(diamond versus round) of arbour holes.

 Blades

that do not match the mounting hardware of the saw
will run eccentrically, causing loss of control.

8.

Never use damaged or incorrect blade washers or
bolt.

 The blade washers and bolt were specially

designed for your saw, for optimum performance and
safety of operation.

1.

Lever

2.

Clamping screw

3.

Cutting line (0° position)

4.

Cutting line (45° position)

5.

Switch trigger

6.

Lock-off button

7.

Hex wrench

8.

Shaft lock

9.

Loosen

10. Tighten
11. Inner flange
12. Saw blade
13. Outer flange
14. Hex bolt
15. Mounting shaft
16. Ring
17. Dust nozzle
18. Screw

19. Vacuum cleaner
20. Hose
21. Rip fence
22. Triangular rule
23. Limit mark
24. Screwdriver
25. Brush holder cap

Model

HS7601

Blade diameter

190 mm

Max. cutting depth

at 0°

66 mm

at 45°

46 mm

No load speed

5,200 min

-1

Overall length

309 mm

Net weight

4.0 kg

Safety class

/II
