10 ENGLISH

Connecting a vacuum cleaner

Optional accessory

1

2

1. Dust nozzle (optional accessory)   2. Screw

(optional accessory)

When you wish to perform clean cutting operation,

connect a Makita vacuum cleaner to your tool. Install

the dust nozzle (optional accessory) on the tool using

the screw. Then connect a hose of the vacuum cleaner

to the dust nozzle as shown in the figure.

OPERATION

CAUTION:

Be sure to move the tool forward in

a straight line gently.

 Forcing or twisting the tool will

result in overheating the motor and dangerous kick-

back, possibly causing severe injury.

NOTE:

 When the battery cartridge temperature is

low, the tool may not work to its full capacity. At this

time, for example, use the tool for a light-duty cut for

a while until the battery cartridge warms up as high

as room temperature. Then, the tool can work to its

full capacity.

Hold the tool firmly. The tool is provided with both a

front grip (motor housing) and rear handle. Use both to

best grasp the tool. If both hands are holding saw, they

cannot be cut by the circular saw blade. Set the base on

the workpiece to be cut without the circular saw blade

making any contact. Then turn the tool on and wait until

the circular saw blade attains full speed. Now simply

move the tool forward over the workpiece surface,

keeping it flat and advancing smoothly until the sawing

is completed.

To get clean cuts, keep your sawing line straight and

your speed of advance uniform. If the cut fails to prop-

erly follow your intended cut line, do not attempt to turn

or force the tool back to the cut line. Doing so may bind

the circular saw blade and lead to dangerous kickback

and possible serious injury. Release switch, wait for cir

-

cular saw blade to stop and then withdraw tool. Realign

tool on new cut line, and start cut again. Attempt to

avoid positioning which exposes operator to chips and

wood dust being ejected from saw. Use eye protection

to help avoid injury.

Rip fence (Guide rule)

Optional accessory

The handy rip fence allows you to do extra-accurate

straight cuts. Simply slide the rip fence up snugly

against the side of the workpiece and secure it in

position with the screw on the front of the base. It also

makes repeated cuts of uniform width possible.
