10 ENGLISH

Dust box

CAUTION:

Do not touch saw dust and the

dust box with bare hands immediately after the

operation.

 They may be extremely hot and could

burn your skin.

CAUTION:

Do not cut the material on which

thinner, gasoline, grease, or other chemicals are

applied.

 The saw dust of such materials can damage

the dust box and result in breakage which can cause

personal injury.

CAUTION:

Wear eye protection or goggle

when emptying the dust box.

Saw dust is collected into the dust box. Periodically

dump the saw dust in the dust box before it gets full.

Push the lever on the dust box to open the lid. Dump

the saw dust while the rear of the tool faces downward.

►

Fig.9:

1.

 Lid

2.

 Lever

►

Fig.10

Hook

Optional accessory

CAUTION:

Always remove the battery when

hanging the tool with the hook.

CAUTION:

Never hook the tool at high loca-

tions or on the surfaces where the tool may lose

the balance and fall.

CAUTION:

Do not pull the tool downward

when it is hooked.

CAUTION:

Always fold the hook when operat

-

ing the tool.

The hook is convenient for hanging the tool temporarily.

►

Fig.11

Attach the hook with the screws as illustrated.

►

Fig.12:

1.

 Hook

2.

 Screw

To use the hook, simply turn the hook until it snaps into

the open position.

When not in use, always turn the hook until it snaps into

the closed position.

►

Fig.13:

1.

 Open position

2.

 Closed position

Electric brake

This tool is equipped with an electric blade brake. If the

tool consistently fails to quickly stop the circular saw

blade after switch lever release, have tool serviced at a

Makita service center.

CAUTION:

The blade brake system is not a

substitute for blade guard. NEVER USE TOOL

WITHOUT A FUNCTIONING BLADE GUARD.

SERIOUS PERSONAL INJURY CAN RESULT.

ASSEMBLY

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed

before carrying out any work on the tool.

Hex wrench storage

When not in use, store the hex wrench as shown in the

figure to keep it from being lost.

►

Fig.14:

1.

 Hex wrench

Installing or removing the circular

saw blade

CAUTION:

Use only the Makita wrench to

install or remove the circular saw blade.

CAUTION:

When installing the circular saw

blade, be sure to tighten the bolt securely.

CAUTION:

Be sure the circular saw blade is

installed with teeth pointing up at the front of the

tool.

►

Fig.15:

1.

 Shaft lock

2.

 Hex wrench

3.

 Tighten

4.

 Loosen

To remove the circular saw blade, press the shaft lock

fully so that the circular saw blade cannot revolve and

use the hex wrench to loosen the hex bolt. Then remove

the hex bolt, outer flange and circular saw blade.

►

Fig.16:

1.

 Hex bolt

2.

 Outer flange

3.

 Circular saw

blade

4.

 Inner flange

5.

 Cup washer

To install the circular saw blade, follow the removal

procedure in reverse.

WARNING:

BE SURE TO TIGHTEN THE HEX

BOLT SECURELY. Also be careful not to tighten

the bolt forcibly. Slipping your hand from the hex

wrench can cause a personal injury.

WARNING:

If the inner flange is removed,

be sure to install it on the spindle. When install

-

ing, choose a correct side on which protrusion

fits into the circular saw blade hole perfectly.

Mounting the circular saw blade on the wrong side

can result in the dangerous vibration.

Blade guard cleaning

When changing the circular saw blade, make sure to

also clean the upper and lower guards of accumulated

metal chips as discussed in the Maintenance section.

Such efforts do not replace the need to check lower

guard operation before each use.
