8

English

PRECAUTIONS ON USING CIRCULAR SAW

  1. Do not use saw blades which are deformed or

cracked.

  2. Do not use saw blades made of high speed steel.

  3. Do not use saw blades which do not comply with

the characteristics specified in these instructions.

  4. Do not stop the saw blades by lateral pressure

on the disc.

  5. Always keep the saw blades sharp.

  6. Ensure that the lower guard moves smoothly and

freely.

  7. Never use the circular saw with its lower guard

fixed in the open position.

  8. Ensure that the retraction mechanism of the guard

system operates correctly.

  9. Never operate the circular saw with the saw blade

turned upward or to the side.

10. Ensure that the material is free of foreign matters

such as nails.

11. For model C6SS, the saw blades range should be

from 165 mm to 160 mm.

For model C7SS, the saw blades range should be

from 190 mm to 185 mm.

12. Disconnect the plug from the receptacle before

c a r r y i n g   o u t   a n y   a d j u s t m e n t ,   s e r v i c i n g   o r

maintenance.

STANDARD ACCESSORIES

(1) Saw Blade (mounted on tool ) ............................... 1

Dia. 165 mm ............................. C6SS

(

Dia. 190 mm ............................. C7SS

)

(2) Hex. Bar wrench ....................................................... 1

Standard accessories are subject to change without notice.

OPTIONAL ACCESSORIES (sold separately)

(1) Dust Collector Set (D)

Connect the suction hose to collect saw dust with

the vacuum cleaner (see

Fig. 9

).

(2) Washer (A)

............... for 20 mm (Hole dia. of saw blade)

............... for 30 mm (Hole dia. of saw blade)

(3) Guide (with wing-balt)

Optional accessories are subject to change without notice.

APPLICATION

Cutting various types of wood.

PRIOR TO OPERATION

1. Power source

Ensure that the power source to be utilized conforms

to the power requirements specified on the product

nameplate.

2. Power switch

Ensure that the power switch is in the OFF position.

If the plug is connected to a receptacle while the

power switch is in the ON position, the power tool

will start operating immediately, which could cause

a serious accident.

3. Extension cord

When the work area is removed from the power

source, use an extension cord of sufficient thickness

and rated capacity. The extension cord should be

kept as short as practicable.

4. Prepare a wooden workbench (Fig. 1)

Since the saw blade will extend beyond the lower

surface of the lumber, place the lumber on a

workbench when cutting. If a square block is utilized

as a workbench, select level ground to ensure it

is properly stabilized. An unstable workbench will

result in hazardous operation.

CAUTION

To avoid possible accident, always ensure that the

portion of lumber remaining after cutting is securely

anchored or held in position.

5. How to store the hex. bar wrench (Fig. 8)

The hex. bar wrench used for attaching and

detaching the saw blade can be stored in the handle.

ADJUSTING THE POWER TOOL PRIOR TO USE

1. Adjusting the cutting depth

The cutting depth can be adjusted by moving the

base after loosening its lever (A) (

Fig. 2

).

CAUTION

Should this lever (A) remain loosened, it will create

a very hazardous situation. Always thoroughly clamp

it.

2. Adjusting the angle of inclination

By loosening the wing bolt at the scale, the saw

blade can be titled up to maximum angle of 45°

against the base (

Fig. 3

).

The angle of inclination can also be regulated by

loosening the wing bolt at the scale (

Fig. 3

).

Model

C6SS

C7SS

Voltage

230 V

Cutting Depth

90°

57 mm

68 mm

45°

38 mm

46 mm

Power Input

1050 W

No-Load Speed

5500 min

–1

Weight (without cord)

3.2 kg

3.4 kg

SPECIFICATIONS
