9

English

CAUTION

It is very hazardous to allow this wing bolt to

remain loosened.  Always thoroughly clamp it.

3. Regulating the guide (Optional accessory)

The cutting position can be regulated by moving

the guide to the left or right after loosening its wing

bolt.

The guide can be mounted on either the left or the

right side.

CUTTING PROCEDURES

1. Place the saw body (base) on the lumber, and align

the cutting line with the saw blade at the front scale

(

Fig. 4

).

2. Turn ON the switch before the saw blade contacts

the lumber. The switch is turned ON when the trigger

is squeezed, and turned OFF when the trigger is

released.

CAUTIONS

Prior to cutting operation, make sure the material you

are going to cut. If the material to be cut is expected to

generate harmful / toxic dusts, make sure the dust bag or

appropriate dust extraction system is connected with

dust outlet tightly.

Wear the dust mask additionally, if available.

䡬

Before starting to saw, confirm that the saw blade

has attained full-speed revolution.

䡬

Should the saw blade stop or make an abnormal

noise while operating, promptly turn OFF the switch.

䡬

Always take care in preventing the power cord from

coming near to the revolving saw blade.

䡬

Using the circular saw with the saw blade facing

upwards or sideways is very hazardous. Such

uncommon applications should be avoided.

䡬

When cutting materials, always wear protective

glasses.

䡬

When finished with a job, pull out the plug from

the receptacle.

MOUNTING AND DISMOUNTING THE SAW

BLADE

CAUTION

To avoid serious accident, ensure the switch is in the

OFF position, and the power source is disconnected.

1. Dismounting the saw blade

(1) Set the cutting volume at maximum, and place the

Circular Saw as shown in

Fig. 5

.

(2) Depress the lock lever, lock the spindle, and remove

the hexagonal-socket bolt with the hex. bar wrench.

(3) While holding the lower guard lever to keep the

lower guard fully retracted into the saw cover,

remove the saw blade.

2. Mounting the Saw Blade

(1) Thoroughly remove any sawdust which has

accumulated on the spindle, bolt and washers.

(2) As shown in

Fig. 6

, the side of Washer (A) with

a projected center the same diameter as the inner

diameter of the saw blade and the concave side

of Washer (B) must be fitted to the saw blade sides.

* Washer (A) is supplied for 2 types of saw blades

with the hole diameters of 20 mm and 30 mm.

(When buying the Circular Saw, one type of

washer (A) is supplied.)

In case the hole diameter of your saw blade

does not correspond to that of washer (A), please

contact the shop where you purchased the

Circular Saw.

(3) To assure proper rotation direction of the saw blade,

the arrow direction on the saw blade must coincide

with the arrow direction on the saw cover.

(4) Using the fingers, tighten the hexagonal-socket bolt

retaining the saw blade as much as possible. Then

depress the lock lever, lock the spindle, and

thoroughly tighten the hexagonal-socket bolt.

CAUTION

After having attached the saw blade, reconfirm that the

lock lever is firmly secured in the prescribed position.

MAINTENANCE AND INSPECTION

1. Inspecting the saw blade

Since use of a dull saw blade will degrade efficiency

and cause possible motor malfunction, sharpen or

replace the saw blade as soon as abrasion is noted.

2. Inspecting the mounting screws

Regularly inspect all mounting screws and ensure

that they are properly tightened. Should any of the

screws be loose, retighten them immediately. Failure

to do so could result in serious hazard.

3. Maintenance of the motor

The motor unit winding is the very “heart” of the

power tool.

Exercise due care to ensure the winding does not

become damaged and/or wet with oil or water.

4. Inspecting the carbon brushes

For your continued safety and electrical shock

protection, carbon brush inspection and replacement

on this tool should ONLY be performed by a Hitachi

Authorized Service Center.

5. Replacing supply cord

If the replacement of the supply cord is necessary,

this has to be done by the manufacturer of this

agent in order to avoid a safety hazard.

6. Adjusting the base and saw blade to maintain

perpendicularity

The angle between the base and the saw blade has

b e e n   a d j u s t e d   t o   9 0 ° ,   h o w e v e r   s h o u l d   t h i s

perpendicularity be lost for some reason, adjust in

the following manner:

(1) Turn the base face up (

Fig. 7

) and loosen the wing-

bolt (

Fig. 3

).

(2) Apply a square to the base and the saw blade and

turning the slotted set screw with a slotted-head

screwdriver, shift the position of the base to produce

the desired right angle.

7. Service parts list
CAUTION

Repair, modification and inspection of Hitachi Power

Tools must be carried out by a Hitachi Authorized

Service Center.

This Parts List will be helpful if presented with the

tool to the Hitachi Authorized Service Center when

requesting repair or other maintenance.

In the operation and maintenance of power tools,

the safety regulations and standards prescribed in

each country must be observed.
