 English |

17

Bosch Power Tools

1 609 92A 3Z2 | (16.6.17)

106 dB(A). Uncertainty K = 3.0 dB.

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745-2-5:
Cutting wood: a

h

= 3 m/s

2

, K = 1.5 m/s

2

.

The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This
may significantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working
period.

Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.

Assembly

Battery Charging



Use only the battery chargers listed on the accessories
page.

Only these battery chargers are matched to the lith-

ium-ion battery of your power tool.

Note:

The battery supplied is partially charged. To ensure full

capacity of the battery, completely charge the battery in the
battery charger before using your power tool for the first time.

The lithium-ion battery can be charged at any time without re-
ducing its service life. Interrupting the charging procedure
does not damage the battery.

The lithium-ion battery is protected against deep discharging
by the “Electronic Cell Protection (ECP)”. When the battery is
empty, the machine is switched off by means of a protective
circuit: The inserted tool no longer rotates.



Do not continue to press the On/Off switch after the
machine has been automatically switched off.

The bat-

tery can be damaged.

Observe the notes for disposal.

Removing the battery

The battery

3

 is equipped with two locking levels that should

prevent the battery from falling out when pushing the battery
unlocking button

24

 unintentionally. As long as the battery is

inserted in the power tool, it is held in position by means of a
spring.

To remove the battery

3

, press the battery unlocking button

24

 and pull the battery out of the power tool toward the rear.

Do not exert any force.

Battery Charge-control Indication (see figure F)

The three green LEDs of the battery charge-control indicator

32

 indicate the charge condition of the battery

3

. For safety

reasons, it is only possible to check the status of the charge
condition when the machine is at a standstill.

Press button

31

 to indicate the charge condition. This is also

possible when the battery

3

 is removed.

When no LED lights up after pushing button

31

, then the bat-

tery is defective and must be replaced.

Mounting/Replacing the Saw Blade



Before any work on the power tool, remove the battery.



When mounting the saw blade, wear protective gloves.

Danger of injury when touching the saw blade.



Only use saw blades that correspond with the charac-
teristic data given in the operating instructions.



Do not under any circumstances use grinding discs as
the cutting tool.

Selecting a Saw Blade

An overview of recommended saw blades can be found at the
end of this manual.

Removal of the Saw Blade (see figure A)

For changing the cutting tool, it is best to place the machine
on the face side of the motor housing.

– Press the spindle lock button

14

 and keep it pressed.



The spindle lock button 14 may be actuated only when
the saw spindle is at a standstill.

Otherwise, the power

tool can be damaged.

– With the hex key

16

, unscrew the clamping bolt

22

 turning

in rotation direction



.

– Tilt back the retracting blade guard

7

 and hold firmly.

– Remove the clamping flange

21

 and the saw blade

20

 from

the saw spindle

18

.

Mounting the Saw Blade (see figure A)

For changing the cutting tool, it is best to place the machine
on the face side of the motor housing.

– Clean the saw blade

20

 and all clamping parts to be assem-

bled.

– Tilt back the retracting blade guard

7

 and hold firmly.

– Place  the  saw  blade

20

 onto the mounting flange

19

. The

cutting direction of the teeth (direction of arrow on the saw
blade) and the direction-of-rotation arrow on the retract-
ing blade guard

7

 must correspond.

– Mount  the  clamping  flange

21

 and screw in the clamping

bolt

22

 turning in rotation direction



. Observe correct

mounting position of mounting flange

19

 and clamping

flange

21

.

– Press the spindle lock button

14

 and keep it pressed.

LED

Capacity

Continuous lighting 3 x green

≥

2/3

Continuous lighting 2 x green

≥

1/3

Continuous lighting 1 x green

< 1/3

Flashing light 1 x green

Reserve
