16

 | English

1 609 92A 3Z2 | (16.6.17)

Bosch Power Tools



Do not open the battery.

Danger of short-circuiting.

Protect the battery against heat, e. g., against
continuous intense sunlight, fire, water, and
moisture.

Danger of explosion.



In case of damage and improper use of the battery, va-
pours may be emitted. Ventilate the area and seek
medical help in case of complaints.

The vapours can irri-

tate the respiratory system.



Use the battery only in conjunction with your Bosch
power tool.

This measure alone protects the battery

against dangerous overload.



The battery can be damaged by pointed objects such as
nails or screwdrivers or by force applied externally.

An

internal short circuit can occur and the battery can burn,
smoke, explode or overheat.

Product Description and Specifica-
tions

Read all safety warnings and all instruc-
tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

While reading the operating instructions, unfold the graphics
page for the machine and leave it open.

Intended Use

The machine is intended for lengthways and crossways cut-
ting of wood with straight cutting lines as well as mitre cuts in
wood while resting firmly on the workpiece.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.

1

Lock-off button for On/Off switch

2

On/Off switch

3

Battery pack *

4

Blade guard

5

Lever for retracting blade guard

6

Base plate

7

Retracting blade guard

8

Parallel guide

9

Cutting mark, 0 °

10

Cutting mark, 45 °

11

Wing bolt for bevel-angle preselection

12

Wing bolt for parallel guide

13

Scale for mitre angle

14

Spindle lock button

15

Auxiliary handle (insulated gripping surface)

16

Hex key

17

Handle (insulated gripping surface)

18

Saw spindle

19

Mounting flange

20

Saw blade *

21

Clamping flange

22

Clamping bolt with washer

23

Marks on the blade guard

24

Battery unlocking button

25

Fastening screw for extraction adapter

26

Extraction adapter

27

Vacuum hose *

28

Cutting-depth scale

29

Clamping lever for cutting-depth preselection

30

Set of screw clamps *

31

Button for charge-control indicator *

32

Battery charge-control indicator *

33

Guide rail *

34

Connection piece *

* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.

Technical Data

Noise/Vibration Information

Sound emission values determined according to
EN 60745-2-5.

Typically the A-weighted noise levels of the product are:
Sound pressure level 95 dB(A); Sound power level

Circular Saw

GKS 18 V-LI

Article number

3 601 F6H 0..

Rated voltage

V=

18

No-load speed

min-1

3 900

Cutting depth, max.

– for  0 °  bevel  angle
– for  45 °  bevel  angle

mm
mm

51
40

Spindle lock



Base plate dimensions

mm

146 x 272

Saw blade diameter, max.

mm

165

Saw blade diameter, min.

mm

160

Blade thickness, max.

mm

1.7

Blade thickness, min.

mm

1.0

Tooth thickness/setting, max.

mm

2.6

Mounting bore

mm

20

Weight according to
EPTA-Procedure 01:2014

kg

3.4–4.1 *

Permitted ambient temperature

– during charging
– during  operation

**

 and during

storage

° C

° C

0 ... + 45

– 20 ... + 50

Recommended batteries

GBA 18 V ...

Recommended chargers

AL 18..

GAL 3680

* depending on the battery pack being used

**

limited performance at temperatures < 0 ° C
