3. Rotation only

This rotary hammer can be set to rotation only mode
by pressing the push button and turning the change
lever to the   mark (

Fig. 8

).

To drill wood or metal material using the drill chuck
and chuck adapter (optional accessories), proceed as
follows.
Installing drill chuck and chuck adapter (

Fig. 9

).

(1) Attach the drill chuck to the chuck adapter.
(2) The part of the SDS-plus shank is the same as the

drill bit. Therefore, refer to the item of “Mounting the
drill bit” for attaching it.

CAUTION

䡬

Application of force more than necessary will not
only expedite the work, but will deteriorate the tip
edge of the drill bit and reduce the service life of the
rotary hammer in addition.

䡬

Drill bits may snap off while withdrawing the rotary
hammer from the drilled hole. For withdrawing, it is
important to use a pushing motion.

䡬

Do not attempt to drill anchor holes or holes in
concrete with the machine set in the rotation only
function.

䡬

Do not attempt to use the rotary hammer in the
rotation and striking function with the drill chuck and
chuck adapter attached. This would seriously shorten
the service life of every component of the machine.

4. When driving machine screws (Fig. 10)

First, insert the bit into the socket in the end of chuck
adapter (D).
Next, mount chuck adapter (D) on the main unit
using procedures described in 4 (1), (2), (3), put the
tip of the bit in the slots in the head of the screw,
grasp the main unit and tighten the screw.

CAUTION

䡬

Exercise care not to excessively prolong driving time,
otherwise, the screws may be damaged by excessive
force.

䡬

Apply the rotary hammer perpendicularly to the screw
head when driving the screw; otherwise, the screw
head or bit will be damaged, or driving force will not
be fully transferred to the screw.

䡬

Do not attempt to use the rotary hammer in the
rotation and striking function with the chuck adapter
and bit attached.

5. When driving wood screws (Fig. 10)

(1) Selecting a suitable driver bit

Employ plus-head screws, if possible, since the driver
bit easily slips off the heads of minus-head screws.

(2) Driving in wood screws

䡬

Prior to driving in wood screws, make pilot holes
suitable for them in the wooden board. Apply the bit
to the screw head grooves and gently drive the screws
into the holes.

䡬

After rotating the rotary hammer at low speed for a
while until the wood screw is partly driven into the
wood, squeeze the trigger more strongly to obtain
the optimum driving force.

CAUTION

Exercise care in preparing a pilot hole suitable for the
wood screw taking the hardness of the wood into
consideration. Should the hole be excessively small
or shallow, requiring much power to drive the screw
into it, the thread of the wood screw may sometimes
be damaged.

6. Hammering only

This rotary hammer can be set to hammering only
mode by pressing the push button and turning the
change lever to the   mark (

Fig. 11

).

(1) Mount the bull point or cold chisel.
(2) Press the push button and set the change lever to

middle of

 mark and   mark (

Fig. 12

).

The rotation is released, turn the grip and adjust the
cold chisel to desired position (

Fig. 13

).

(3) Turn the change lever to   mark (

Fig. 11

).

Then bull point or cold chisel is locked.

7. Using depth gauge (Fig. 14)

(1) Loosen the knob on the side handle, and insert the

depth gauge into the mounting hole on the side
handle.

(2) Adjust the depth gauge position according to the

depth of the hole and tighten the knob securely.

8. How to use the drill bit (taper shank) and the taper

shank adapter

(1) Mount the taper shank adapter to the rotary hammer

(

Fig. 15

).

(2) Mount the drill bit (taper shank) to the taper shank

adapter (

Fig. 15

).

(3) Turn the switch ON, and drill a hole in prescribed

depth.

(4) To remove the drill bit (taper shank), insert the cotter

into the slot of the taper shank adapter and strike the
head of the cotter with a hammer supporting on a
rests (

Fig. 16

).

HOW TO USE THE CORE BIT
(FOR LIGHT LOAD)

When boring penetrating large holes use the core bit (for
light loads). At that time use with the center pin and the
core bit shank provided as optional accessories.

1. Mounting
CAUTION

Be sure to turn power OFF and disconnect the plug
from the receptacle.

(1) Mount the core bit to the core bit shank (

Fig. 17

).

Lubricate the thread of the core bit shank to facilitate
disassembly.

(2) Mount the core bit to the rotary hammer (

Fig. 18

).

(3) Insert the center pin into the guide plate until it stops.
(4) Engage the guide plate with the core bit, and turn the

guide plate to the left or the right so that it does not
fall even if it faces downward (

Fig. 19

).

2. How to bore (Fig. 20)

(1) Connect the plug to the power source.
(2) A spring is installed in the center pin.

Push it lightly to the wall or the floor straight.
Connect the core bit tip flush to the surface and start
operating.

(3) When boring about 5 mm in depth the position of the

hole will be established. Bore after that removing the
center pin and the guide plate from core bit.

(4) Application of excessive force will not only expedite

the work, but will deteriorate the tip edge of the drill
bit, resulting in reduced service life of the rotary
hammer.

CAUTION

When removing the center pin and the guide plate,
turn OFF the switch and disconnect the plug from the
receptacle.
