14

 | English

u

In case of damage and improper use of the battery, va-
pours may be emitted. The battery can set alight or ex-
plode.

Ensure the area is well ventilated and seek medical

attention should you experience any adverse effects. The
vapours may irritate the respiratory system.

u

Do not open the battery.

There is a risk of short-circuit-

ing.

u

The battery can be damaged by pointed objects such
as nails or screwdrivers or by force applied externally.

An internal short circuit may occur, causing the battery to
burn, smoke, explode or overheat.

u

Only use the battery with products from the manufac-
turer.

 This is the only way in which you can protect the

battery against dangerous overload.

Protect the battery against heat, e.g. against
continuous intense sunlight, fire, dirt, water
and moisture.

 There is a risk of explosion and

short-circuiting.

u

Hold the power tool firmly with both hands and make
sure you have a stable footing.

 The power tool can be

more securely guided with both hands.

Product Description and
Specifications

Read all the safety and general instructions.

Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.

Please observe the illustrations at the beginning of this oper-
ating manual.

Intended Use

The power tool is intended for hammer drilling in concrete,
brick and stone, as well as for light chiselling work. It is also
suitable for drilling without impact in wood, metal, ceramic
and plastic. Power tools with electronic control and right/left
rotation are also suitable for screwdriving.

Product Features

The numbering of the product features refers to the diagram
of the power tool on the graphics page.

(1)

SDS plus drill chuck

(2)

SDS plus tool holder

(3)

Dust protection cap

(4)

Locking sleeve

(5)

Button for depth stop adjustment

(6)

Release button for impact/mode selector
switch

(7)

Impact/mode selector switch

(8)

Rotational direction switch

(9)

On/Off switch

(10)

Handle (insulated gripping surface)

(11)

Battery

A)

(12)

Worklight

(13)

Battery release button

A)

(14)

Auxiliary handle (insulated gripping surface)

(15)

Depth stop

(16)

Button for battery charge indicator

A)

(17)

Battery charge indicator

A)

(18)

Universal holder with SDS plus shank

A)

A)

Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.

Technical Data

Cordless rotary hammer

GBH 180-LI

Article number

3 611 J11 1..

Rated voltage

V=

18

Rated speed

– Clockwise

min

-1

0−1800

– Anticlockwise

min

-1

0−1800

Impact rate

A)

min

-1

0−5100

Impact energy per stroke ac-
cording to EPTA-Procedure
05:2016

J

2

Tool holder

SDS-plus

Max. drilling diameter

– Concrete

B)

mm

20

– Steel

mm

13

– Wood

mm

30

Weight according to EPTA-
Procedure 01:2014

A)

kg

2.8−3.7

Permitted ambient temperat-
ure

– During charging

°C

0 to +35

– During operation

C)

 and

during storage

°C

–20 to +50

Recommended batteries

GBA 18V...

ProCORE18V

4.0A/8.0Ah

Recommended chargers

GAL 18...

GAX 18...

GAL 36...

A) Depends on battery in use
B) Optimum performance with driling diameter 6−10 mm
C) Limited performance at temperatures <0 °C

Noise/Vibration Information

Noise emission values determined according to

EN 60745-2-6

.
