www.timberk.com • electric air purifier

4

1. Air Purifier - 1 pc.

2. Filter – 2 pc

3. Manual and warranty Card - 1 pc

4. Packing - 1 pc.

On/Off:

Connect t to power, then press the «    »  bottom, the unit will start

working, and last for 8 hours automatically. If press «    » bottom again, it
will stop working.

Timer:

Press it to select setting time form 1h-4h-8h.

Function selection:

 press it once to select the wind mode from sleeping-

Normal-powerful; If press it for 3 second, you could turn on the ion function
also. Press it for 3 second again, you could turn it off.

Change of Filter

Suggest you to change the filter once per 6 months.

Remove the cover of filter, take out the 2 filter, then change 2 new ones.

1. Air outlet

2. Front cover

3. Display board

4. Rear cover

4. PRODUCT DESCRIPTION

5. COMPLETE SET

6. OPERATION OF THE INSTRUMENT

5. Carbon fiber filter

6. Cold catalyst and HEPA filter

7. Cover of filter

8. Power Supply

Fig. 1

1. The low fan speed indicator

2. The medium fan speed indicator

3. The high fan speed indicator

4. Indicator lamp ionizer

5. Fan Speed Button

Fig. 2

1

2

3

4

5

8

6 7

9

10

1

2

5

6

7
8

3

4

6. Indicator Sleep Timer 1 hour

7. The indicator Sleep Timer 4 hours

8. The indicator Sleep Timer 8 hours

9. The timer button

10. Button on/off
