www.timberk.com • electric ceiling heater

8

Fig. 9

WARNING!

After installation of the heater and before switching for

the first time, it is necessary to wipe the radiating board

with alcohol. After that, it is PROHIBITED to touch the

radiating board.

Connection to electric mains

1.  The patio heater is designed to be connected to 220V~, 50Hz single-

phase voltage mains with a grounding circuit.
2. Prior to connection make sure that parameters of electric mains in the

place of connection comply with parameters, indicated on the identification

plate with technical data of the unit.
3. It is necessary to follow active electrical safety precautions, connecting

the convector to electric mains.
4.  An electric outlet must be properly grounded. The outlet must be

designed for rated current not less than 16A for models with maximum

power up to 2000W. Electric outlet and plug must always stay dry to

prevent current leakage. Regularly check if the electric plug is tightly

connected to the outlet. It must be done in the following order: connect an

electric plug into an outlet, after half hour operation turn off the patio heater

and disconnect the plug from the outlet, check if the plug is heated by your

hand. If the plug heated over 50°C then replace the outlet by a new one

to prevent damages, incidents, fire as a result of bad electric contact. A

specialist must do the job.

1.  Before switching on the heater, ensure that no moisture on the device

and on the heating element.
2.  After the first turn the heater on may appear briefly burnt smell. This

7. OPERATION OF THE INFRARED HEATER

WARNING!

Warning! Please connect the cable with an industrial

plug rated  3P 230V~ 16A IP67 of IEC 60309-2
