Timberk TFH T20MDR - Инструкция по эксплуатации - Страница 5

www.timberk.com • Electric metal ceramic fan heater

5

6. CONTROL OF THE FAN HEATER

Рис. 2

1. Switcher

Used to select the mode of heating power:

•

 Mode “I” (ventilation with heat on 1/2 power)

•

 Mode “0” (switch off of the device)

•

 Mode “II” (ventilation with heat at full power)

2. Thermostat handle

Used to set the desired room temperature

Control panel

Unit operation

1. Connect the power cord to a wall outlet. Do not use the appliance on

uneven surfaces, near flammable or deformable objects

2. To activate the heater, you must install the key switch to «I» position or

«II», choosing comfortable for you to heating mode

3. Thermostat knob set the desired level of heat the air in the room.

Thermostat maintains the desired temperature by automatically disable

and enable the electric heater (temperature range from 0 °C to 40 °C).

To increase the desired temperature, turn the thermostat knob hourly

arrows to reduce - counterclockwise.

4. If you want to turn off the heater, set the switch to «0» («OFF) and Switch

off the appliance from the mains.

Before starting a preventive cleaning, make sure that switcher is set to «0»

(«Off»), and the unit is de-energized.

Recommendations for regular cleaning:
disconnect the unit from the mains by unplugging the power cord from the

electrical outlet, allow to cool, then wipe it with a soft, slightly damp cloth.
Cleaning is not recommended to use detergents, including tools with

abrasive compounds.
Do not damage the surface of the instrument with a sharp object.

7. MAINTENANCE

WARNING!

Heater is not intended for uncontrolled use of children,

the elderly or people with disabilities. Operate the heater

carefully, switching modes sharply, strictly follow the

guidelines outlined in this instruction manual.
Children that are near the heater must be supervised by

adults. Do not allow the use of heater as an element of

the game.

NOTE:

During the first use of heater may cause odor and

smoke. Do not worry, it means that at the time of

production to the heating element has got a drop of oil.

Drop quickly evaporate - the smell and the smoke will

not happen
