www

.timberk.com • electric convector heater

8

• When the current temperature is higher than setting temperature of 1

degree, the appliance will be power off.
• When the current temperature is lower than setting temperature of 1

degree, the appliance will be power on.

10. Button «TIMER ON»

When in standby, press the button of «TIMER ON», the display screen

show number 1 for power on, press the button «UP» again, the display

screen would show number 2, the max timer is 24 hours, press the button

of «DOWN», the number would be decrease 1.

11. Button «TIMER OFF»

When in power on, press the button of «TIMER OFF», the display screen

show number 1 for power off by alarm, the light would be off in the same

time, press the button «UP» again, the display screen would show number

2, the max timer is 24 hours, and press the button of «DOWN», the number

would decrease 1.

12. Function «CHILD LOCK»

• Press the button «UP»/«DOWN» for 3 second, the keyboard lock will be

on, the light of «LOCK» would be on, the screen would be flashing, it will

become to be the previous setting after 5 seconds; when the keyboard is

on, any key is no working.
• For unlock press «UP»/«DOWN» for 3 seconds again, the appliance

would be unlocked.

13. LED-display

Displays the current temperature value or time settings.

14. «POWER» indicator

Lights up when starts heating mode

15. «Standby» indicator

Lights up when convector connecting to electric main

16. «LOCK» indicator

Lights up when control panel is locked

17. «NSV» indicator

Lights up when it tests the voltage when the product starts working, if the

voltage  below ~180V or over ~240V, the lamp are light.

18. «ELCB» indicator

Lights up when it tests the grounding function when the product starts

working, if it isn’t connect the ground, the lamp are light.

19. «ERR» indicator

Lights up when if there is something wrong in the product, the lamp are light.

9. SERVICE

10. TROUBLESHOOTING

IMPORTANT!

See «Rules for safe operation and installation of electric

convector»

In the process of using an electric convector on the intake, outlet grill or

on the device may appear dust or other contamination. To preserve the

health and appearance of the device must be regularly cleaned from dust

and dirt. Before cleaning the external surfaces of the electric convector,

disconnect the appliance from the mains and allow it to cool completely.

Clean the outside of the appliance with a damp, soft cloth and then wipe

dry and allow the device to dry completely. Do not use abrasive cleaning

agents. Do not damage the appliance with a sharp object, as scratches on

painted surfaces can cause rust.

If you are not able to remedy a malfunction according to the

recommendations or other malfunctions occur, contact the authorized

service center of Timberk.

Troubleshooting

Possible causes

Removal

Electric convector is
connected to the mains,
switch handle Mode is set to
heating but convector  does
not work.

1. No power.
2. Violated contacts in the wiring diagram
of the circuit.
3. Defective switch modes

1. Check whether the power supply is
disconnected from the device and, if
necessary, post power to the appliance.
2. Restore reliable connection contacts.
3. Refer to a specialist repair service center
Timberk.

Electric convector is
connected to the mains,
switch handle modes of
operation is set to the
heating, but the heating is not
going on.

1. The thermostat is set to temperature
lower than in the room.
2. Temperature limiter parted electrical
circuit and shut off the heating elements.
3. Defective switch modes.
4. Defective power relay.
5. Faulty thermostat.
6. Defective heating element.
7. Faulty temperature limiter.

1. Set the thermostat to a higher
temperature heat the room, turning the
thermostat knob clockwise.
2. Ensure that the air inlet or outlet grill is
not blocked by foreign objects and wait for
the inclusion of the temperature limiter,
after the body of the device to cool.
3-7. Refer to a specialist repair service
center Timberk.
