ENGLISH

14

21. This device can be used by children from 8 years up and per-

sons with reduced physical, sensory or mental capacities or

lack of experience and knowledge if they have been given the

appropriate supervision and training on using the device in a

safe way and understand the dangers involved.

22. Children should not play with the appliance.

23. Before carrying out any cleaning or maintenance operation,

make sure the device is unplugged from the mains.

24. The cleaning and maintenance to be done by the user must not

be done by children.

25. Do not clean the device while it is working and do not immerse

it in water.

26. Do not handle the appliance with wet hands.
27.

 Device designed for internal use.

2. DESCRIPTION OF THE DEVICE / CONTROL PANEL (FIGURE 1)

a) Hot air outlet grille.

b) LCD control screen.

c) Control panel.

d) Main switch (ON / OFF).

e) Thermostat  probe.

3. INSTALLATION (FIGURE 4)

CAUTION: Before installing the device, read all the Safety Warnings in the relevant section

of this manual carefully.

As far as possible, you should install this Wall Heater under a window, but never in a draughty

area.

3.1.  With a Ø 6mm bit, drill the three holes (1-2-3) according to the measures indicated, then

insert the wall plugs (Fig. 4 A).

3.2.  In the top two holes fix the hook-shaped wall supports (Fig. 4 A).

3.3.  Hang the appliance on these supports and then secure it so it cannot come unfastened.

Insert the support in the central grooves of the bottom grille and fix it with the corres-

ponding screw (Fig. 4B).

4. ELECTRICAL CONNECTION

CAUTION: Before connecting the device, check the supply voltage of the electricity network

matches the one stated on the type label of the device.
