Thermozone AD  Corinte W  - ADCS

23

GB

3. Put the unit in place and fix the brackets to

the pendulums.

Note! The unit needs to be secured if hung
from wires.

Electrical installation

The unit has cable and plug.

The installation, which should be preceded

by an omnipolar switch with a contact
separation of at least 3 mm, should only
be wired by a competent electrician and in
accordance with the latest edition of IEE
wiring regulations.

The control system is pre-installed in the

aircurtain with an integrated control card,
(see fig 8).

SIRe is supplied pre-programmed with

quick-release connections.

Modular cables are connected to the control

board Base, by opening the front plate, as
shown in Figure 4 and 5. See manual for SIRe.

Change connection side of water coil

If you wish to connect the water coil in the
opposite orientation to that delivered, remove
the front panel (see Fig 4). To take out the
water coil, see Fig 3.
1. Unscrew the outer screws from the coil with

for example a hexagonal key ¼”. See Fig. 3.

2. Loosen the inner screws on the coil, but do

not remove them on the air curtain.

3. Lift out the water coil and turn it.
4. Mount the coil in reverse order.

Connection of water coil

The air curtain has an aluminium finned
heating coil with copper tubes suitable for
connection to a closed water heating system.
The heating coil must not be connected to
a mains pressure water system or an open
water system.

The unit is connected from above or below

to Ø22 mm copperpipes, by compression
fitting or through welding the pipe work to the
unit.

The upper side of the heating coil is

equipped with ventilating valve in the unit.
The heating coil should be ventilated before
operation to prevent air locks.

When mounting the unit vertically, water

connection can be carried out from the top or

bottom. The connection from below can be
done the following way:

•  Flexible hoses may be drawn through

drilled holes in the floor and connected to
the air curtain pipes. The flexible hoses are
connected to the system beneath the floor.

Note! At connection from below, avoid placing
hoses or pipes so that they obstruct the air
flow to the fans. If necessary, secure them to
avoid vibrations and prevent them from being
sucked into the fans.

When mounting the unit horizontally, water

connection can be carried out from the left
or right. The lid on the top side of the unit
is sliding to be adjustable to the water pipe
dimension. (see Fig 6a).

Adjustment of air flow

The direction and speed of the air flow
should be adjusted considering the load on
the opening. Compressive forces affect the
air stream and make it bend inwards into the
premises (when the premises are heated and
the outdoor air is cold). The air stream should
therefore be directed outwards to withstand
the load. (Generally speaking, the higher the
load, the bigger the angle needed.)

With an hexagon key, loosen the three

screws supporting the outlet grille. Angle the
grille outwards to obstruct the incoming cold
air.

Overheating

The over heat protection maintains the
exhaust temperature at +40 °C.  If the
temperature should exceed anyway there is
an over heating alarm. For more information
see the manual for SIRe.
