Thermozone AD300 W, AD400 W

25

General recommendations

Carefully read this instruction manual before instal

-

lation and use of the AD 300/400W

unit. Keep these

instructions in a safe place for future reference.

Application area

The Thermozone AD 300/400W air curtains are

intended for stationary/permanent installation above

entrances and smaller doors with a height from 2

up to 4.5 meters, but can also be used for industrial

heating and drying. The AD 300/400W has been

designed for connection to a low-pressure hot water

supply. The unit can be mounted above a doorway or

recessed into a ceiling.

Protection class: IP20

Operation

The air is drawn in at the top of the unit and blown

out at high velocity across the doorway, providing a

protective air shield. The air shield minimises cold

draughts and reduces heat loss through open door

-

ways. For best eficiency, the air curtain(s) should

cover the whole width of the opening.

The air director/grille is adjustable and is normally

angled outwards (5-10°) to achieve the best protec

-

tion.

The airlow can be adjusted by use of the fan speed

selector (CB30/221AG)

The eficiency of the air curtain(s) depends on the

air temperature and pressure differences across the

doorway and any wind pressure.

NOTE! Negative pressure in the building considera

-

bly reduces the eficiency of the air curtain. Ventila

-

tion should therefore be balanced.

Mounting

The units may only be installed horizontally over a

doorway with the air-stream directed downwards.

For the protection of wider doorways, several units

can be mounted next to each other. For optimal

performance it is recommended that a minimum gap

of 120mm is maintained above the air-curtain.

The units can be itted to the wall or suspended from

the ceiling. Two or three (AD320/420) mounting con

-

soles are included with the air-curtain. The M6 bolts

(2 or 3) which slot into the to the aluminium proile

on top of the unit can slide sideways, allowing the

consoles to be mounted at different distances from

each other. (See details on page 2-3.)

Fitted on the wall

1.  Mount the consoles to the wall, see ig. A or B,

page 3

2. Loosen the nuts on the upper side of the air curtain

to be able to it the consoles between the nut and

the unit.

3.  Mount the unit on to the consoles and tightened

the nuts.

Mounting in false ceiling

See ig. C on page 3.

Mounting with suspension kit (extra)

When using the brackets for pendulum ixing ADPF1

see ig. D on page 4 or ADPK1 see ig E on page 4.

Electrical installation

The air-curtain(s) should only be wired by a competent

electrician, and in accordance with the latest edition of

IEE wiring regulations.

1   Remove the front plate by pressing a

 screwdriver or similar in to the two holes (Ø

 5 mm) underneath the edge of the front plate.

Press until it clicks and the front plate can be

 opened and removed. See Fig. on page. 3

2   Remove the lid of the connection box by

removing the two screws placed on the right

 side of the unit. Remove the knockouts on top

of the unit (4xØ23mm) for routing of electrical

supply and remote switching cables.

Different combinations of fan speed and heat

output are detailed in the wiring diagrams on

pages 4-6.

Adjusting the air curtain and air stream

The direction and the velocity of the air stream should

be adjusted in regard to the load on the doorway. Pres

-

sure forces the air stream to bend towards the interior

of the room (when the room is heated and the exterior

is cold).

The air stream should be directed outwards to resist

the pressure. An angle up to 15° is recommended. THe

more load caused by negative pressure, temperature

differences and wind, the more should the air beam be

directed outwards.

Basic air low settings

The air low is set with the air low selector so that the

speed of the air is 3-4 m/s 1m above the loor. The

direction of the air beam and the air speed may need

to be adjusted more exactly depending on the load on

the door.

GB
