15

b) Changing

tools

- To insert or remove a tool with CENTROTEC

shaft, pull the green release ring (2.10)

back. On inserting the tool, turn it until its

hex shank arbour (2.9) locks in place in the

hexagonal shank of the drill spindle, and

push the tool into the toolholder as far as

it will go.

3.5   Tool  holding

fi

 xture in the drill

spindle

Bits can be

fi

 tted directly in the hexagon

socket holder of the drill spindle (2.5) to

make the machine lighter and shorter.

4

Charge battery pack

To load the battery pack, push it into the

holder (3.1) on the charger up to the stop.

Perform this in reverse to remove the battery

pack from the charger. The battery type used

(NiCd or NiMH) is detected automatically.

Charging is controlled by a microprocessor.

If a warm NiMH battery pack (>37° C) is

inserted, charging will only be carried out

at a lower charge current. In this case, the

charging time is extended.

The LED (3.2) indicates the respective
charging state of the charger.
LED yellow – steady:

  Charger is ready for use.

LED green –

fl

 ashing:

  Battery pack being charged.

LED green – steady:

  Battery pack fully charged, conservation

charge on.

LED red –

fl

 ashing:

  General malfunction, e. g. full contact not

being made, short-circuit, battery pack

faulty.

LED red – steady:

  Temperature of battery pack is outside

permissible limit.

It is essential that you read
the instructions in the Chapter
„Working instructions - Mainte-
nance - Care“.

5

Working with the machine

5.1   Initial operation

Turn on by pressing button (1.3). Depending

on the pressure exerted on the button, the

adjustment of running speed can be varied

in

fi

 nitely. Turn off by releasing the button

(1.3).

After releasing the button, the chuck is

stopped and therefore, after-running of the

equipment is prevented.

5.2

Bit storage well

You can insert several bits or bit extensions

into the bit magazine (1.2) with magnetic

holder.

5.3   Warning signal

With the following operational statuses, the

machine sounds an acoustic warning signal

and switches off:

Peep at regular intervals

- Battery empty

Triple peep at regular intervals

- Excessive load (torque)

- Machine too warm.

6

lnstructions on application -
maintenance - care

Please pay attention to the fol-
lowing instructions. Otherwise
there is a risk of damage to the
tool, charger or battery pack.

- Repairs may only be performed by author-

ised technicians. LC 45 charging device:

Even after disconnection from the mains,

there is still a high capacitor voltage on the

power output component on the inside of

the device.

- Keep the air vents of the electronic equip-

ment and the charger clean to guarantee

the air circulation for cooling.

- No metal objects (metal chips) should

enter the charger at the contact points as

well as through the cooling slits into the

equipment (danger of short circuit).

- Only use original Festool battery packs.

  Do not use spent and recycled battery

packs. The user shall be liable for dam-

ages if Festool original battery packs are

not used.

- Keep the connection contacts of electronic

equipment, charger and battery pack

clean.

- By keeping the battery pack in a ready for

use charger, the battery pack will be kept

in a state of readiness by

fl

 oat  charging

conservation.

- Do not keep discharged battery pack

(maximum one month) attached to charger

whenever charger is detached from the
