13

b)

Machine-related safety instruc-
tions

- Charger and power tool are not intended

for use by persons (including children) with

limited physical, sensory or mental ability

or without suf

fi

 cient experience and/or

knowledge, unless they are supervised by a

person responsible for their safety or have

been instructed on how the charger or pow-

er tool is to be used. Children should always

be supervised to ensure that they do not

play with the charger or the power tools.

- Always hold the machine by the insulated

handles if there is a possibility of drilling

into hidden power cables.

- Take care when drilling into walls as there is

a danger of rupturing concealed gas/water

pipes or cutting through power cables.

- Do not open the battery pack or the

charger. Even after disconnection from the

mains, there is still a high capacitor voltage

inside the charger.

- Make sure that metal objects (such as

metal chips) do not collect in the battery

pack retaining slots or enter the machine

through the air vent slits (danger of short

circuit).

- Protect the battery pack from excessive

heat or constant heat sources such as

sunlight or naked

fl

 ames. There is a risk

of explosion.

- Never use water to extinguish burning LiIon

battery packs, always use sand.

1.3   Noise and vibration information
Cordless drill/screwdriver

The typical values determined in accordance

with EN 60745 are:

Sound pressure level

65 dB(A)

Sound-power level

76 dB(A)

Measuring uncertainty allowance  K = 3 dB

  The noise level can exceed 85 dB(A)

during operation.

Wear ear protection!

Vibration emission value a

h

 (vector sum for

three directions) and uncertainty K meas-

ured in accordance with EN 60745:

Drilling in metal

 a

h

 < 2,5 m/s²

K = 1,5 m/s²

Screws

a

h

 < 2,5 m/s²

K = 1,5 m/s²

The emission values speci

fi

 ed  (vibration,

noise) were measured in accordance with

the test conditions stipulated in EN 60745

and are intended for machine comparisons.

They are also used for making preliminary

estimates regarding vibration and noise

loads during operation.

The emission values speci

fi

 ed refer to the

main applications for which the power tool

is used. If the electric power tool is used

for other applications, with other tools or is

not maintained suf

fi

 ciently prior to opera-

tion, however, the vibration and noise load

may be higher when the tool is used. Take

into account any machine idling times and

downtimes to estimate these values more

accurately for a speci

fi

 ed time period. This

may signi

fi

 cantly reduce the load during the

machine operating period.

1.4   Wall mounting LC 45

The charger LC 45 has two longitudinal slots

on its rear by which it can be suspended on

walls using two screws (e.g. button-headed

or

fl

 at head screw with a shaft diameter of

5 mm). Screw both screws into the wall

96 mm apart until the screwhead is protrud-

ing from the wall by approx. 4 mm.

2

Machine settings

Remove the battery pack before any adjust-

ments, maintenance or repair is carried out!

2.1   Exchanging the battery pack
Removing battery pack

Press the two buttons (1.1) and slide the

battery pack forwards to remove.

Inserting battery pack

Slide the battery pack into the holder on the

underside of the handle until it latches into

place (see Fig. 1).

2.2   To change the direction of rotation

The selector button (1.4) determines the

direction of rotation.

Turn button from right to left =

clockwise

rotation.

Turn button from left to right =

anticlockwise rotation.

Selector button in

central position =

circuit interlock.

2.3   Shifting speeds

Change only when completely
stopped!

Using the shift lever (1.5), the speed can

be changed.
