EN

17

Removing condensation from the air tube

If there is moisture or liquid remaining in the air tube, be sure to follow the procedure

below to remove any moisture from within the air tube.

1)  Make sure that the air tube is connected to the air connector on the compressor.

2)  Remove the air tube from the nebulizer kit.

3)  Turn on the compressor and pump air through the air tube to expel the moisture.

Changing the air filter

If the air filter has been used for more than 60 days, replace it with a new one.

1.

Pull the air filter cover off the compressor.

2.

Change the air filter.

3.

Put the air filter cover back in place.
Make sure it is attached properly.

Notes:

•

Use only OMRON air filters designed for this device. Do not operate without air filter.

•

Do not wash or clean the air filter. If the air filter becomes wet, replace it. Damp air filters

can cause blockages.

•

There is no front or back orientation for the air filters.

•

Check that air filters are clean and free of dust before inserting them.

Troubleshooting

Check the following if the device should fail during operation.

Problem

Cause

Remedy

Nothing happens

when the power switch

is pressed.

Is the AC adapter connected

correctly to a power outlet and

the compressor?

Check that the AC adapter is connected

to a power outlet and the compressor.

Unplug then reinsert the plug if necessary.

No nebulization or

low nebulization rate,

when the power is on.

Is there medication in the

medication tank?

Add the correct amount of medication to

the medication tank.

Is there too much/little

medication in the medication

tank?
Is the vaporizer head missing

or not assembled correctly?

Attach the vaporizer head correctly.

Is the nebulizer kit assembled

correctly?

Assemble the nebulizer kit correctly.

Is the nozzle blocked?

Make sure that the nozzle is free of

blockages.

Is the nebulizer kit tilted at a

sharp angle?

Make sure that the nebulizer kit is not

tilted at an angle of more than 45 degrees.

Is the air tube connected

correctly?

Make sure that the air tube is correctly

connected to the compressor and

nebulizer kit.

Is the air tube folded?

Make sure that the air tube is not twisted

or bended.

Is the air tube blocked?

Make sure that the air tube is free of

blockages.

Is the air filter dirty?

Replace the air filter with a new one.

The compressor is

abnormally loud.

Is the air filter cover attached

correctly?

Attach the air filter cover correctly.

The compressor is

very hot.

Is the compressor being

covered?

Do not cover the compressor during

operation.

Note:

If the suggested remedy does not solve the problem, do not try to repair the

device - the device are not user serviceable. Return the device to an authorized

OMRON retail outlet or distributor.
