SUB 10000-13000 DS / TWIN 11000-14000

ORIGINAL INSTRUCTIONS FOR USE

Contents

About  this  handbook........................................ 14
Product  description.......................................... 14
Scope  of  delivery............................................. 15
Safety  instructions............................................ 15
Assembly.......................................................... 16
Startup.............................................................. 16
Maintenance  and  care..................................... 17
Storage............................................................. 17
Disposal............................................................ 17
Help in case of malfunctions............................ 18
Warranty........................................................... 19
EU declaration of conformity............................ 19

ABOUT THIS HANDBOOK

Read  this  documentation  before  starting  up

the  machine.  This  is  a  precondition  for  safe

working and flawless operation.
Observe  the  safety  warnings  in  this  docu-

mentation and on the product.
This  documentation  is  a  permanent  integral

part  of  the  product  described  and  must  be

passed on to the new owner if the product is

sold.

Explanation of symbols

CAUTION!

Following  these  safety  warnings  care-

fully  can  prevent  personal  injury  and/or

material damage.

ADVICE

Special  instructions  for  greater  ease  of

understanding and improved handling.

PRODUCT DESCRIPTION

This  documentation  describes  various  different

models of immersion pumps. Identify your model

using the identification plate.

Product overview
TWIN

(Fig. A)

1 Connection cable with mains plug

2 Carrying handle
3 Motor housing
4 Combination adapter
5 Adjustable foot
6 Suction slots
7 Elbow nipple
8 Pump housing
9 Engaging screws

10 Float switch

SUB

(Fig. C)

1 Connection cable with mains plug
2 Carrying handle
3 Motor housing
4 Combination nipple
5 Adjustable foot
6 Suction slots
7 Level switch housing
8 Level switch

Function

The  immersion  pump  draws  the  conveying  me-

dium through the suction slots directly and feeds

it to the pump outlet at the combination nipple. It

is  switched  on  and  off  using  a  float  switch.  The

switching movement of the float switch can be ad-

apted to suit by adjusting the cable length on the

float switch or by adjusting the level switch on the

housing.

Adjusting foot setting

TWIN pumps

SUB pumps

"U" -

bottom

Clear and waste

water can be

conveyed.

"O" -

top

only clear water

can be conveyed

Water can be

drawn off very

flat
