Cleaning the pump
•
When laying the suction hose, make sure
that it is lower than the pump.
If you have used your garden pump to pump
chlorine water (swimming pool water) or liquids
which leave a residue, flush your pump out with
clear water after use.
If the suction hose is laid so that it is higher
than the pump, bubbles will be- come
trapped in the line and the pump will suck
air.
Cleaning the filter
•
Fill the suction hose.
•
Remove the draining screw (10) from the
draining opening; drain the filter chamber
and close the draining opening again.
Attaching the pressure hose
•
Screw the threaded connection nipple (20)
with the round seal ring (21) into the pump
outlet (3).
•
Remove filter cover (11) with the help of the
filter spanner.
•
Remove filter (13) from pump head and
clean it under running water.
•
Attach the elbow nipple (18) to the connec-
tion nipple (20) and turn the nipple so that it
points in the desired direction.
•
Prior to assembling the filter, check the two
seals (12) on the filter and seal (16) for dam-
age, if necessary renew.
•
Attach a hose to the elbow nipple.
•
Clear the pressure line (open valves, spray-
ers, etc.).
The seal (16) must be correctly inserted in
the seal seat on pump head (see detail in
Fig. B). If necessary, lightly grease the seal
with non-acidic fat.
Filling the garden pump
Before putting your garden pump into
operation, you must fill it with water until it
overflows to achieve full suction power. Do
not operate the pump while it is dry be-
cause this will cause serious damage to
the pump.
•
Mount the filter, screw the filter cover, and
tighten firmly with the filter spanner - hand
tight.
Removing, cleaning and installing the
non-return valve
•
Remove the filler screw (2).
•
Remove the filter (see section "Cleaning the
filter").
•
Pour water into the opening until the cham-
ber of the pump (8) is full.
•
Remove the non-return valve (14) and clean
it under running water.
•
Replace the filler screw (2) and tighten it.
Switching the pump on and off
•
If necessary, renew the seal (15).
•
Install the non-return valve.
•
Plug the electric cable into the socket.
•
Install the filter and filter cover
Make sure that the pump does not run on a
blocked or closed pressure hose.
Frost protection
•
Draining the suction hose and pressure
hose.
•
Clear the pressure line (open valves, spray-
ers, etc.).
•
Unscrew the draining screws (9) and (10)
and allow the water to flow out of the pump.
•
Switch the pump on by pushing the switch
(6) to On.
•
Screw the draining screw back again and
store the pump frost free.
•
Switch the pump off by pushing the switch
(6) to Off.
Switching off the system
RL 2002/96 EC
Do not dispose of worn-out
units through the household
garbage!
The appliance, its packaging and
accessories are all produced from
recyclable materials and must be
disposed of accordingly.
•
Switch the system off by unplugging the
electric cable from the socket.
Maintenance and Cleaning
Before beginning any maintenance or
cleaning work, make sure that the garden
pump has been unplugged and take
precautions to ensure that it cannot be
switched on during work!
Translation of original user instructions
GB 3
