Use

GB 2

             Translation of original user instructions

Designated use

The garden pump is designed for home use in
your house or garden. Please observe the tech-
nical data given in the instructions before putting
the pump into operation.
Your garden pump has been designed for use in
the following applications:
–  irrigation and watering, e.g. of your lawn or

flower and vegetable gardens,

–  emptying containers or pumping liquid from

one container into another (e.g. swimming
pools),

–  pumping water from wells, rain drums or

cisterns.

The system is designed to pump only the follow-
ing liquids:
– clear

water,

– rain

water,

–  chlorine water (pool water).

Prohibited use

Your garden pump is not intended for permanent
operation. The pump may not be used to pump
the following liquids:
– drinking

water

– saltwater,
–  beverages or liquid foods,
–  corrosives or chemicals,
–  acids or combustible, explosive or gas-

forming liquids,

–  liquids with a temperature above 35 °C,
–  sandy water or water containing abrasives.

Description of the pump

Garden pump/accessories (Figs. A, B,C)

1  Pump inlet/suction hose connector
2 Filler

screw

3  Pump outlet/pressure hose connector
4 Motor

housing

5 Electric

cable

6 On/Off

switch

7 Suction

body

8 Pump

chamber

9  Draining screw for pump chamber
10  Draining screw for filter chamber
11  Transparent filter cover
12  Seals for filter
13 Filter
14 Non-return valve
15 Seal
16  Round seal (transparent cover – filter cham-

ber)

17 Flat seal

18 Elbow nipple
19 Flat seal
20 Connection nipple
21 Round seal
22  Pressure hose (accessory)
23  Suction fitting (accessory)

Filter spanner (Fig. B)


The accessory is not part of the scope of
supply.

Function

The garden pump sucks the liquid to be pumped
into the pump through the suction hose (1) and
pumps it via the filter out of the outlet (3).
Use the On/Off switch (6) to switch the garden
pump on or off as desired.

Thermal protection

Your pump is equipped with a thermal protection
switch, which switches the pump off if it over-
heats. The pump will remain off until it has
cooled down. After about 15 - 20 minutes, the
pump will automatically switch on.

Setting up and operating the
system

•

  Place the garden pump onto a hard, flat

surface so that it cannot tip over and so that
it will not be near the flow of water.

•

  Make sure that the pump is protected from

rain   and any direct exposure to water.

Attaching the suction hose

Choose a hose which is long enough so
that the pump will not suck in air and run
dry. The hose should be at least 30 cm
under the surface of the liquid to be
pumped while the pump is in operation.

•

  Attach the suction hose. Make sure to screw

it in tightly, but take care not to damage the
threads.


If the liquid to be pumped is deeper than 4
m, you should use a suction hose which is
larger than 1“ in diameter for the best
performance. We recommend our AL-KO
suction set (23), which consists of a
suction hose, strainer and non-return
valve. The suction set is available at your
local retailer’s.
