Original instructions for use

467 771_a

11

ORIGINAL INSTRUCTIONS FOR USE

Contents

About  this  handbook........................................ 11
Product  description.......................................... 11
Scope  of  supply............................................... 12
Safety  instructions............................................ 12
Assembly.......................................................... 12
Startup.............................................................. 13
Maintenance  and  care..................................... 13
Storage............................................................. 13
Disposal............................................................ 13
Help in case of malfunctions............................ 14
Warranty........................................................... 15
EU declaration of conformity............................ 15

ABOUT THIS HANDBOOK

Read  this  documentation  before  starting  up

the  machine.  This  is  a  precondition  for  safe

working and flawless operation.
Observe  the  safety  warnings  in  this  docu-

mentation and on the product.
This  documentation  is  a  permanent  integral

part  of  the  product  described  and  must  be

passed on to the new owner if the product is

sold.

Explanation of symbols

CAUTION!

Following  these  safety  warnings  care-

fully  can  prevent  personal  injury  and/or

material damage.

ADVICE

Special  instructions  for  greater  ease  of

understanding and improved handling.

PRODUCT DESCRIPTION

This  documentation  describes  various  different

models of immersion pumps. Identify your model

using the identification plate.

Product overview

1 Connection cable with mains plug
2 Carrying handle

3 Float switch cable
4 Pump housing
5 Float switch
6 Suction slots
7 Connection elbow
8 Combination nipple
9 Venting (only Drain 10000/15000 INOX)

Function Drain 10000 / 12000

The  immersion  pump  draws  the  conveying  me-

dium through the suction slots directly and feeds

it to the pump outlet at the combination nipple. It

is switched on and off using a float switch.

Function Drain 10000 INOX / 15000 INOX

The  immersion  pump  draws  the  conveying  me-

dium through the suction slots directly and feeds it

to the pump outlet. It is switched on and off using

a float switch. In order to operate properly, the im-

mersion pump must be vented at the venting fa-

cility.

Inox stainless steel

Units  marked  with  the  designation  "INOX"  are

supplied in stainless steel. The structure and func-

tion are unaffected by this.

Designated use

The immersion pump is designed for private use

in the house and garden. It must only be operated

within the framework of the deployment limitations

in accordance with the technical data.
The immersion pump is suitable for:

Water removal in the event of a flood
Re-pumping  and  pumping  out  from  vessels

(e.g. swimming pools)
Water removal from streams and shafts
Water removal from drains and trickle shafts.

The immersion pump is only suitable for convey-

ing the following fluids:

Clear water, rainwater
Chlorine-containing  water  (e.g.  swimming

pools)
Waste water
Dirty water having a max. suspended matter

proportion of 5 % and a grain size of max. 30

mm diameter.
